Table 8: CVM03050 Controller accessories (Order Separately)
Product code number Description
Y65A13-0
Transformer, 120 VAC Primary to 24 VAC Secondary, 40 VA,
Foot Mount (Y65AS), 20.32 cm (8 in.), Primary Leads and
76.2 cm (30 in.) Secondary Leads, Class 2
Y65T31-0
Transformer, 120/208/240 VAC Primary to 24 VAC
Secondary, 40 VA, Foot Mount (Y65AR+), 20.32 cm (8 in.),
Primary Leads and Secondary Screw Terminals, Class 2
Y65T42-0
Transformer, 120/208/240 VAC Primary to 24 VAC
Secondary, 40 VA, Hub Mount (Y65SP+), 20.32 cm (8 in.),
Primary Leads and Secondary Screw Terminals, Class 2
F-1000-325
Replacement Barbed Fitting for Connecting Tubing, Bulk
Pack of 10. For use on CVM03050-0, and also on VMA1630,
VMA1615, and VMA1832 Series models.
F-1000-326
Flexible Tubing Extension with Barbed Fitting for
CVM03050-0x, VMA1630, VMA1615, and VMA1832, 35.56
cm (14 in.) Length. Bulk Pack of 20.
Use to extend tubing that connects between the DPT
connectors and the DPT sensors, including when replacing
a VMA1400 series controller with a CVM03050-0x, VMA16xx
or VMA18xx controller.
MS-FIT100-0
The Field Inspection Tool (FIT) is a portable handheld
device with a user interface that is used to test and
troubleshoot the BACnet protocol MS/TP RS-485
communications bus that connects supervisory controllers
and equipment controllers to field point interfaces.
The FIT can be used to check out the wiring of the MS/
TP RS-485 bus as well as verify proper communications
of supervisory controllers and equipment controllers
connected to the bus. The FIT can be used on both the FC
Bus and SA Bus.
31F4-CVM VAV Terminal Equipment Controllers Installation Instructions
