Ordering information and accessories
The following tables provide the product code number and description for the CVM03050 models
and accessories.
Table 7: CVM Series Ordering Information
Product code
number
Description
F4-CVM03050-0
VAV Box Controller with Integrated Actuator and Digital Differential
Pressure Transducer (DPT) Sensor.
Includes MS/TP (and N2) communication; 8 points (3 UI, 2 CO, and 3 BO);
real-time clock; 32-bit microprocessor; 24VAC input.
F4-CVM03050-0P
VAV Box Controller with Integrated Actuator, Position Feedback, and DPT
Sensor.
Includes MS/TP (and N2) communication; 8 points (3 UI, 2 CO, and 3 BO);
real-time clock; 32-bit microprocessor; 24VAC input.
Note: The following CVM03050 models are also available:
• Bulk Pack Models: F4-CVM03050-0D, F4-CVM03050-0PD
Table 8: CVM03050 Controller accessories (Order Separately)
Product code number Description
FX-PCX Series Expansion Input/
Output Modules
Refer to the FX-PC Series Programmable Controllers and
Related Products Product Bulletin (LIT-12011657) for a
complete list of available FX-PCX Expansion I/O Modules.
FX-FCP-0
License enabling Facility Explorer Equipment Controller
Firmware Package Files required for CCT
Mobile Access Portal (MAP)
Gateway
Refer to the Mobile Access Portal Gateway Catalog Page
(LIT-1900869) to identify the appropriate product for your
region.
Note: The MAP Gateway serves as a replacement for
the BTCVT, which is no longer available for purchase,
but continues to be supported.
FX-DIS1710-0 Local Controller Display
NS-ATV7003-0 Handheld VAV Balancing Tool
NS Series Network Sensors
Refer to the NS Series Network Sensors Product Bulletin
(LIT-12011574) for specific sensor model descriptions.
AS-CBLTSTAT-0
Cable adapter for connection to 8-pin TE-6700 Series
sensors
NS-WALLPLATE-0 Network Sensor Wall Plate
ZFR1800 Series Wireless Field Bus
System
Refer to the ZFR1800 Series Wireless Field Bus System Product
Bulletin (LIT-12011336) for a list of available products.
Y64T15-0
Transformer, 120/208/240 VAC Primary to 24 VAC
Secondary, 92 VA, Foot Mount, 72.2 cm (30 in.), Primary
Leads and 76.2 cm (30 in.) Secondary Leads, Class 2
