Table 9: CVM03050 Controllers technical specification
Dimensions
(Height x Width x Depth)
165 mm x 125 mm x 73 mm (6.5 in. x 4.92 in. x 2.9 in.)
Center of Output Hub to Center of Captive Spacer: 135 mm
(5-5/16 in.)
Weight 0.69 kg (1.52 lb)
United States:
UL Listed, File E107041, CCN PAZX, UL 916, Energy Management
Equipment.
FCC Compliant to CFR47, Part 15, Subpart B, Class A.
Suitable for Use in Other Environmental Air Space (Plenums)
in Accordance with Section 300.22(C) of the National Electrical
Code.
Canada:
UL Listed, File E107041, CCN PAZX7, CAN/CSA C22.2 No. 205,
Signal Equipment.
Industry Canada Compliant, ICES-003
Europe:
CE Mark – Johnson Controls declares that this product is in
compliance with the essential requirements and other relevant
provisions of the EMC Directive and RoHS Directive.
Australia and New Zealand:
RCM Mark, Australia/NZ Emissions Compliant.
Compliance
BACnet International: BACnet Testing Laboratories
™
(BTL)
Protocol Revision 15 Listed and Certified BACnet Advanced
Application Controller (B-AAC), based on ANSI/ASHRAE 135-2016
1 The VA rating does not include any power supplied to the peripheral devices connected to Binary Outputs (BOs) or
Configurable Outputs (COs), which can consume up to 12 VA for each BO or CO, for a possible total consumption of an
additional 60 VA (maximum).
2 For more information, refer to the MS/TP Communications Bus Technical Bulletin (LIT-12011034).
The performance specifications are nominal and conform to acceptable industry standard. For
application at conditions beyond these specifications, consult the local Johnson Controls office. Johnson
Controls shall not be liable for damages resulting from misapplication or misuse of its products.
F4-CVM VAV Terminal Equipment Controllers Installation Instructions34
