Johnson Controls FAC2611 User Manual

Table 5: Termination details
Type of field
device
Type of Input/
Output
Termination diagrams
0–10 VDC Output
to Actuator
(Internal Source)
CO or AO
0–10 VDC Output
to Actuator
(External Source)
CO or AO
Current Output CO or AO
24 VAC Triac
Output (Switch
Low, External
Source)
CO or AO
Analog Output
(Current)
AO
FAC2611 Advanced Application Field Equipment Controller Installation Guide 13
