Network Room Module Technical Bulletin 14
Table 7: Configuration Properties
Name/Description Property Name Data Type Default Limits
Space Temperature
Setpoint High Limit
SpaceTempSetptHighLimit Analog -
Temperature
28.0°C (82.5°F) Max. 40°C (99.5°F)
Space Temperature
Setpoint Low Limit
SpaceTempSetptLowLimit Analog -
Temperature
12.0°C (53.5°F) Min. 0°C (32.0°F)
Temporary Occupied
Time
TemporaryOccupiedTime Analog - minutes 60 min 0 to 255 min
Fan Configuration
FanConfiguration
1
Enumeration – fan
speed
Three speed 0, 1, 2, 3
Setpoint
Configuration
(absolute or offset)
SetpointConfig
2
Binary logic 0 = Absolute Absolute or Offset
Temperature Units
(display units °C or °F)
TemperatureUnits
3
Binary logic 0 = SI (°C) SI or US
Enable Space
Temperature Display
(defines if space
temperature is shown)
EnableSpaceTempDisplay Binary logic ON=Enabled OFF or ON
Default Absolute
Setpoint
DefaultAbsoluteSetpt Analog -
temperature
21°C (70°F) 0 to 40°C
(32 – 99.5°F)
Back-light Time-out
BackLightTime
4
Analog - seconds 30 sec 0 to 60 seconds
Temperature Sensor
Offset
TemperatureOffset Analog – temp.
diff.
0°C
±5°C
(
±9°F)
Enable Unoccupied
State Blink
EnableUnoccupiedBlinking Binary logic ON=Enabled OFF or ON
Enable Maintenance
Icon
EnableMaintDispIcon Binary logic ON=Enabled OFF or ON
Physical Address
PhysicalAddress Integer 191 191 to 194
1. 0=None, 1=One speed fan, 2=Two speed fan, 3=Three speed fan
2. 0=Absolute Setpoint, 1=Offset Setpoint (±3°C) (±5°F)
3. 0=SI (°C), 1=US (°F)
4. 0=No back-light, >60=Back-light always on
