Johnson Controls Facility Explorer - Ordering Codes

Network Room Module Technical Bulletin 32
Parameter/Component
(Cont.)
Value/Description
Shipping Weight
0.2 kg (7 oz.), 80 x 80 mm (3.15 x 3.15 in.) housing or
0.25 kg (9 oz), 120 x 80 mm (4.72 x 3.15 in.) housing
Compatible
FX Controllers and
Firmware Versions
FX06
V 2.32 and higher
FX07
V 3.01 and higher
FX14
V 2.32 and higher
FXVMA
All versions
Europe
– 2004/108/EEC, EMC Directive: EN 61000-6-3, EN 61000-6-2
Canada
UL Listed (PAZX7), C22.2 No. 205, Signal Equipment
Industry Canada, ICES-003
Compliance
United
States
UL Listed (PAZX), UL 916, Energy Management Equipment
FCC compliant to CFR 47, Part 15, Subpart B, Class A
Table 12: Recommended FX Controller and MUI/NRM Configuration Limits
FX Controller Type MUI/NRM Configuration Limits
FX06
One MUI and one NRM
FX06 Rev A
One MUI and one NRM
FX07
One MUI and one NRM
FX07 Rev A
One MUI and one NRM
FX14
One MUI and two NRMs
1
FX14 Rev A
One MUI and two NRMs
1
FX14 Rev B
One MUI and two NRMs
1
FX15 Universal
NRM is not supported
FX15
NRM is not supported
FX15 Rev A
NRM is not supported
FX16
NRM is not supported
FX16 Rev A
NRM is not supported
FX16 Rev B
NRM is not supported
FXVMA
One MUI and one NRM
FXVMA Rev A
One MUI and one NRM
1. One addressable NRM is required.
Ordering Codes
Table 13: Network Room Modules Ordering Information (Available in Europe)
Features/Options
Product Code
Size
(mm)
Service
Port Type
LCD
Display
Temperature
Adjustment
Dial
Fan
Speed
Selector
Button
°F/°C
Button
Addressable
LP-NRM001-000C
No No No No No
LP-NRM002-000C
Yes Yes No No No
LP-NRM003-000C
Program
Key
Yes Yes Yes No No
LP-NRM511-000C
No No No No Yes
LP-NRM502-000C
Yes Yes No No No
LP-NRM503-000C
80 x 80
MUI
Yes Yes Yes No No
