Network Room Module Technical Bulletin 16
Key Concepts
Location of the Network Room Module
Choose a location for the NRM, taking the following information into
consideration:
• Place the NRM where the occupant can easily read the LCD and use
the controls.
• Place the NRM where the ambient temperature is representative of the
general room conditions if you want to use the built-in temperature
sensor to measure space temperature. For example, there should be
sufficient air circulation.
• Avoid cold or warm air drafts, radiant heat, and direct sunlight.
• Place some insulating material in the wiring access hole or conduit to
prevent the introduction of air from outside the room.
IMPORTANT: The installation of electrical wiring must conform to local codes
and should be carried out by authorized personnel only. Users should ensure
that all Johnson Controls® products are used safely and without risk to health or
property.
