Johnson Controls FEC26 Series User Manual

Table 4: FEC26 Terminal Blocks, Functions, Ratings, Requirements, and Cables
Determine Wire Size and Maximum
Cable Length
Function, Ratings, RequirementsTerminal LabelTerminal Block
Label
See Guideline C in Table 5.
Binary Output - 24 VAC Triac (External
Power Source)
Connects OUTn to OCOMn when
activated.
External Power Source Requirements:
30 VAC maximum output voltage
0.5 A maximum output current
1.3 A at 25% duty cycle
40 mA minimum load current
OUTn
BINARY
(Output)
Power Selection
Jumper positioned
to External (EXT)
power.
Binary Output Common (for OUTn
terminal)
Note: Each Binary Output Common
terminal (OCOMn) is isolated from
all other commons, including
other Binary Output Common
terminals.
OCOMn
See Guideline C in Table 5.
Binary Output - 24 VAC Triac (Internal
Power Source)
Sources internal 24 VAC power (24~
HOT).
OUTn
BINARY
(Output)
Power Selection
Jumper positioned
to Internal (INT)
power.
Binary Output - 24 VAC Triac (Internal
Power Source)
Connects OCOMn to 24~ when activated.
Internal Power Source:
30 VAC maximum output voltage
0.5 A maximum output current
1.3 A at 25% duty cycle
40 mA minimum load current
OCOMn
16FEC26 Field Equipment Controllers Installation Instructions
