FIRECLASS Fire detection system Mounting a FC702/708/718 panel to the wall
Installation Guide Doc. version 2.0 8
85 240 85
27
40
378 75
330 40
410
205
214.5
480
Fig. 3: FC702D, FC718D and FC708D panels - Mounting plate fixing and overall dimensions in mm
1– Mounting frame holes
