Hardware Installation—Installing the IFC-1010/2020
M501MJ
M50XMJM5X0CJM500XJ
SLC
SLC
XPP
To N ex t
Device on
Channel A
BGX-101
B501BJ Base
SLC Loop Maximums:
99 Module Addresses
99 Detector Addresses
40 ohms total loop resistance (LIB-200)
10,000 feet of loop (LIB-200)
amslc2
ADDRESS
LOOP
12 11 10 9 8 7 6 5 4 3 2 1
P5
P1 P2 P3
JP3
ADDRESS
LOOP
Figure 75: Typical SLC Loop (Style 4)
