Hardware Installation—Installing the IFC-1010/2020
13
Installation Overview
The basic equipment package for the Johnson Controls IFC-2020 is the
BE-2020 and the basic equipment package for the Johnson Controls
IFC-1010 is the BE-1010. The following list may be used to identify
various components in a received BE-2020 and/or BE-1010 shipment.
Refer to Circuit/Device Ratings and Connections Technical Bulletin
(LIT-448160) for an optional equipment listing.
•
cables
- MPS to ICB Power Cable (71030 or 75378)
- CPU/MPS Supervisory Cable (71031)
•
BP-3 Battery Dress Panel
•
CPU-2020(BE-2020) or CPU-2 (BE-1010) Central Processor Unit
•
DIA-1010 or DIA-2020 Display Interface Assembly
- CPU to DIB cable (75226)
N11
•
ICA-4L Interconnect Chassis Assemblies
To obtain a complete understanding of specific features within the
IFC-1010/2020 or to become familiar with functions in general, make use
of the documentation noted in Table 1 or use the VeriFire™ Windows®
based offline programming and test utility, which reduces installation
programming time.
Table 1: Related Documentation
Document FAN or LIT Number
IFC-1010/2020 Technical Manual
FAN 448
500 Series Intelligent Modules Technical Bulletin
LIT-408100
LCD-80 Liquid Crystal Display Technical Bulletin
LIT-445151
Device Compatibility Technical Bulletin
LIT-445180
NIB-96 Network Interface Board Technical Bulletin
LIT-445101
LDM Lamp Driver Modules Technical Bulletin
LIT-445161
Installing the Fire Fighters Command Center Technical
Bulletin
LIT-448165
XP5 Series Transponders Technical Bulletin
LIT-445230
Basic
Equipment
Related
Documentation
