Hardware Installation—Installing the IFC-1010/2020
113
The IFC-1010/2020 can employ PRN-4 Remote Printers. This printer
provides a hardcopy printout of all status changes within the system and
time stamps the printout with the current time of day and date. The PRN-4
provides 80 columns of data on standard 9 inch by 11 inch tractor-feed
paper.
Remote printers require 120 VAC, 50/60 Hz primary power (battery
backup) is not provided; the use of a separate Uninterruptable Power
Supply (UPS) 50 watt minimum, UL Listed for Fire Protective Signaling
is recommended.
Connection between the control panel and PRN-4 is provided through an
EIA-232 interface on the Serial Interface Board. An installer provided
cable must be assembled for connection to the printer’s EIA-232 port.
Refer to Figure 82 for wiring instructions.
Using a special print feature, the PRN-4 allows all information
programmed into the panel to be printed out (including system
configuration and addressable device parameters).
Note: The PRN-4 is factory programmed.
Remote
Printers
Installation
