Hardware Installation—Installing the IFC-1010/2020
15
Cabinet and Component
Installation
The cabinet assembly consists of two basic components; the backbox
(SBB) and door (DR). All cabinets for the IFC-1010/2020 are fabricated
from 16-gauge steel.
Cabinet parts are painted gray or red with navy blue windows.
Provided with the key-locked door are a pin-type hinge, window,
two keys, and the necessary hardware to mount the door to the backbox.
The backbox has been engineered to provide ease-of-entry, with knockouts
positioned at numerous points to simplify conduit installation.
The hinges are field-selectable for either left or right mounting. The door
opens 180 degrees.
Cabinets are available in sizes A through D.
N2
A trim ring (TR) option is available for semi-flush mounting
(TR-A3, TR-B3, TR-C3, TR-D3).
A wire channel (WC-2) option provides a pair of wire trays to neatly route
wire between tiers in the cabinet. Order one pair per cabinet tier.
N9
The doors may be mounted in either a left or right opening configuration;
aiding in installation and service when two control panels are mounted in a
confined area or side-by-side (as shown in Figure 1). In this manner the
doors may be opened barn door style, creating an open workspace. Note
that in this type of installation it is necessary to leave enough space
between cabinets to insert a key into the locks on the door frames.
General
Product Line
Information
Prior to
Installation
