Hardware Installation—Installing the IFC-1010/2020
79
2(+)
1(-)
3
Loop
AddressType
IGN
Their
nfpaslc6
Connect to
chassis via
Cable 71073.
8
7
6
5
4
3
2
1
Earth Ground
Channel B (-)
No Connection
Channel B (+)
No Connection
Channel A (-)
No Connection
Channel A (+)
Modules
Detectors
Pull Stations
Note: Refer to
and installation drawings supplied with each loop
device for rating and specification information.
Circuit/Device Ratings and Connections Technical Bulletin
(LIT-448160)
LIB-400
LIB
SLC Loop
All terminals are power-limited.
Figure 52: NFPA Style 6 LIB SLC Loop
