FORM 145.05-EG2 (618)
JOHNSON CONTROLS
13
* OPTIONAL
** OPTIONAL HOT WATER OR
ELECTRIC HEA
T
VARIABLE FREQUENCY DRIVE*
SHELL & TUBE CONDENSERS
FAN MOTOR & FRAME
AIR SAFE-OFF
LIFTING LUGS (4)
ELECTRICAL CONTROLS
HOT WATER OUT**
CONDENSER WATER OUT
CONDENSER WATER IN
HOT WATER IN**
FAN INLET & COIL CLEANING ACCESS DOOR
HOT WATER VALVE**
CONDENSATE DRAIN TRAP
FILTER DRIERS
THERMOSTATIC EXPANSION VALVES
HOT WATER COIL**
EVAPORATOR COIL
WATER ECONOMY COIL*
STANDARD AIR FILTERS
HIGH EFFICIENCY FILTERS*
FILTER DRIERS
COMPRESSORS
ELECTRIC HEAT CONTROLS**
CONDENSER WATER VALVES
ELECTRIC HEATER FRAME**
PLENUM FAN
INTERNAL FAN ISOLATION
SEISMIC ISOLATION*
