Johnson Controls LSWU035 Engineering Guide

FORM 145.05-EG2 (618)
JOHNSON CONTROLS
69
Operating Weights
TABLE 30 - OPERATING WEIGHTS (LBS) - LSWU025–060
MODEL LSWU025 LSWU032 LWSU035 LSWU040 LSWU050 LSWU060
Compressor Section
H2O
Weight
H2O
Weight
H2O
Weight
H2O
Weight
H2O
Weight
H2O
Weight
Compressor-Standard 1832 72 1890 72 1941 72 2032 72 3392 144 3512 144
Compressor-High
Efciency
1852 72 1915 72 1971 72 2077 72 3462 144 3592 144
Water Economy Coil 265 55 317 61 374 68 374 68 575 136 575 136
Hot Water Heat 133 25 147 27 160 30 160 30 240 60 240 60
Fan Section
Supply Fan 984 984 984 984 1380 1380
25 Inch Class II 273 273 273 273 - -
28 Inch Class II 358 358 358 358 - -
32 Inch Class II - - - - 428 428
36 Inch Class II - - - - 583 583
Supply Fan Motor
ODP Prem Eff Prem Eff Prem Eff Prem Eff Prem Eff Prem Eff
5HP 175 175 175 175 - -
7.5HP 207 207 207 207 - -
10HP 238 238 238 238 - -
15HP 327 327 327 327 327 327
20HP 367 367 367 367 367 367
25HP 470 470 470 470 470 470
30HP - - - - 512 512
40HP - - - - 614 614
50HP - - - - 622 622
TEFC Prem Eff Prem Eff Prem Eff Prem Eff Prem Eff Prem Eff
5HP 199 199 199 199 - -
7.5HP 260 260 260 260 - -
10HP 341 341 341 341 - -
15HP 365 365 365 365 365 365
20HP 421 421 421 421 421 421
25HP 538 538 538 538 538 538
30HP - - - - 573 573
40HP - - - - 742 742
50HP - - - - 900 900
Variable Frequency Drive (VFD)
Variable Air Volume (VAV) & VAV w/ Bypass
5HP 61 61 61 61 - -
7.5HP 81 81 81 81 - -
10HP 81 81 81 81 - -
15HP 96 96 96 96 96 96
20HP 96 96 96 96 96 96
25HP 115 115 115 115 115 115
30HP 115 115 115 115 115 115
40HP 115 115 115 115 115 115
50HP 190 190 190 190 190 190
Filter Section
4" 30-35% Efciency
(MERV 8)
156 156 156 156 205 205
4" 80–85% Efciency +
4" 30–35% Efciency
Prelter (MERV 13 + 8)
288 288 288 288 391 391
Plenums
Inlet Plenum - Sound
Attenuating
246 246 246 246 290 290
Outlet Plenum - Half 295 295 295 295 415 415
Outlet Plenum - Full 386 386 386 386 355 355
Inlet Plenum - Air
Economy
678 678 678 678 866 866
Electric Heat Section
Fan 89 89 89 89 129 129
**Weights shown represent approximate operating weights and they have a ±10% accuracy.
