Cooling Performance Data
TABLE 8 - LSWU025
AIR FLOW 10,000 CFM
EDB EWB
EWT 80 LWT 90 EWT 80 LWT 92 EWT 85 LWT 95
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
75 62 292 249 52.4 51.7 14.6 68.3 290 248 52.5 51.8 15.0 56.8 287 246 52.6 51.9 15.6 67.9
75 67 311 195 57.6 57.2 14.7 72.2 308 194 57.6 57.3 15.0 59.9 304 193 57.8 57.5 15.6 71.5
75 72 336 141 62.8 62.6 14.7 77.3 334 140 62.9 62.7 15.0 64.2 330 139 63.0 62.9 15.6 76.6
80 62 301 296 53.0 51.3 14.6 70.3 299 294 53.1 51.4 15.0 58.3 296 292 53.3 51.5 15.6 69.7
80 67 312 248 57.7 57.2 14.7 72.4 310 247 57.7 57.2 15.0 60.2 306 245 57.9 57.4 15.6 71.8
80 72 337 194 62.9 62.6 14.7 77.4 334 193 63.0 62.6 15.0 64.3 330 191 63.1 62.8 15.6 76.7
85 62 319 319 55.9 50.6 14.6 73.7 317 317 56.0 50.7 15.0 61.3 313 313 56.4 50.8 15.6 73.3
85 67 323 297 58.1 56.7 14.7 74.7 321 296 58.2 56.8 15.0 62.1 317 294 58.4 56.9 15.6 74.1
85 72 337 246 63.0 62.5 14.7 77.4 335 246 63.0 62.6 15.0 64.3 330 244 63.2 62.7 15.6 76.7
AIR FLOW 10,000 CFM
EDB EWB
EWT 85 LWT 97 EWT 90 LWT 100 EWT 90 LWT 102
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
75 62 284 245 52.8 52.0 15.9 56.4 280.9 243.3 52.9 52.1 16.5 67.4 278.4 242 53.0 52.2 16.9 56.0
75 67 302 192 57.8 57.5 16.0 59.5 297.9 190.4 58.0 57.7 16.5 70.9 295.7 189.5 58.1 57.8 16.9 58.9
75 72 327 138 63.2 63.1 16.0 63.6 323 136 63.3 63.2 16.6 75.9 320 135 63.4 63.3 17.0 63.0
80 62 293 291 53.5 51.6 15.9 57.9 289.9 288.3 53.7 51.7 16.5 69.3 287.4 286.4 53.9 51.8 16.9 57.5
80 67 304 245 57.9 57.4 16.0 59.8 300.6 243 58.1 57.5 16.6 71.4 299 242.3 58.1 57.6 16.9 59.5
80 72 328 190 63.2 62.9 16.0 63.7 323 188.8 63.3 63.0 16.6 75.9 320.4 187.8 63.4 63.1 17.0 63.1
85 62 311 311 56.6 50.9 16.0 60.9 307.5 307.5 56.9 51.0 16.6 72.8 305.4 305.4 57.1 51.1 16.9 60.5
85 67 315 293 58.4 57.0 16.0 61.6 311 290.5 58.6 57.1 16.6 73.5 309 289.5 58.7 57.2 16.9 61.1
85 72 328 243 63.3 62.8 16.0 63.7 323.8 241.4 63.4 62.9 16.6 76.1 320.8 240.3 63.5 63.0 17.0 63.1
HIGH EFFICIENCY - AIR FLOW 8,000 CFM
EDB EWB
EWT 80 LWT 90 EWT 80 LWT 92 EWT 85 LWT 95
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
75 62 297 235 48.5 48.4 14.6 69.4 295 234 48.6 48.5 15.0 57.6 291 232 48.8 48.7 15.6 68.9
75 67 318 188 54.2 54.1 14.7 73.6 316 187 54.3 54.2 15.0 61.2 312 185 54.5 54.4 15.6 72.9
75 72 345 142 59.7 59.6 14.7 79.1 343 141 59.8 59.7 15.0 65.7 338 139 60.0 59.9 15.6 78.3
80 62 306 281 48.1 48.0 14.6 71.2 304 280 48.2 48.1 15.0 59.2 300 278 48.4 48.3 15.6 70.7
80 67 319 233 53.9 53.8 14.7 73.9 317 232 54.0 53.9 15.0 61.3 313 231 54.1 54.0 15.6 73.3
80 72 346 187 59.5 59.4 14.6 79.2 343 186 59.6 59.5 15.0 65.7 338 184 59.8 59.7 15.6 78.4
85 62 319 319 48.5 47.2 14.6 73.9 317 317 48.7 47.4 15.0 61.4 314 314 49.1 47.5 15.6 73.4
85 67 330 280 53.4 53.3 14.6 76.0 327 279 53.5 53.4 15.0 63.1 324 277 53.7 53.6 15.6 75.4
85 72 346 232 59.3 59.2 14.7 79.2 343 231 59.4 59.3 15.0 65.8 339 229 59.6 59.5 15.6 78.4
HIGH EFFICIENCY - AIR FLOW 8,000 CFM
EDB EWB
EWT 85 LWT 97 EWT 90 LWT 100 EWT 90 LWT 102
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
75 62 289 231 48.9 48.8 15.9 57.2 285 229 49.2 49.1 16.5 68.3 283 228 49.3 49.2 16.9 56.7
75 67 309 184 54.6 54.5 16.0 60.6 305 182 54.8 54.7 16.6 72.2 302 181 54.9 54.8 16.9 60.0
75 72 336 138 60.1 60.0 16.0 65.0 331 137 60.3 60.2 16.6 77.5 328 136 60.4 60.3 17.0 64.4
80 62 298 277 48.5 48.4 15.9 58.8 294 275 48.7 48.6 16.5 70.1 292 274 48.8 48.7 16.9 58.3
80 67 311 230 54.2 54.1 16.0 60.9 307 228 54.4 54.3 16.6 72.7 304 227 54.6 54.5 17.0 60.4
80 72 336 183 59.9 59.8 16.0 65.1 331 181 60.1 60.0 16.6 77.6 328 180 60.2 60.1 17.0 64.4
85 62 312 312 49.3 47.6 16.0 61.1 309 309 49.7 47.8 16.6 73.0 306 306 50.0 48.0 16.9 60.7
85 67 321 276 53.8 53.7 16.0 62.6 317 274 54.1 54.0 16.6 74.7 314 273 54.2 54.1 17.0 62.0
85 72 336 228 59.7 59.6 16.0 65.1 332 226 59.9 59.8 16.6 77.7 329 225 60.0 59.9 17.0 64.4
NOTE: EDB-entering dry bulb temp, EWB-entering wet bulb temp, EWT-entering water temp, LWT-leaving water temp, LDB-leaving dry bulb temp,
LWB-leaving wet bulb temp, TMBH-total capacity, SMBH-sensible capacity
