Johnson Controls LSWU035 Engineering Guide

FORM 145.05-EG2 (618)
68
JOHNSON CONTROLS
Electrical Data
TABLE 27 - FAN MOTOR DATA
ODP PREMIUM EFFICIENCY
HORSEPOWER
208/3/60 230/3/60 460/3/60 575/3/60
FLA FLA FLA FLA
5 HP 14 12.7 6.33 5.06
7.5 HP 20.5 18.5 9.25 7.4
10 HP 27.4 24.8 12.4 9.92
15 HP 41.1 37.2 18.6 14.9
20 HP 55.3 50 25 20
25 HP 66.1 59.8 29.9 23.9
30 HP 78.3 70.8 35.4 28.3
40 HP 107 96.4 48.2 38.6
50 HP 132 120 59.9 47.9
60 HP 155 140 69.9 55.9
TEFC PREMIUM EFFICIENCY
HORSEPOWER
208/60/3 230/60/3 460/3/60 575/3/60
FLA FLA FLA FLA
5 HP 14.4 13 6.49 5.19
7.5 HP 20.1 18.1 9.07 7.26
10 HP 27 24.4 12.2 9.76
15 HP 40.3 36.4 18.2 14.6
20 HP 54.6 49.4 24.7 19.8
25 HP 65.2 59 29.5 23.6
30 HP 77.6 70.2 35.1 28.1
40 HP 107 96.4 48.2 38.6
50 HP 131 118 59.2 47.4
60 HP 151 137 68.3 54.6
TABLE 28 - COMPRESSOR MOTOR DATA
NOMINAL
HORSEPOWER
208/3/60 230/3/60 460/3/60 575/3/60
RLA LRA RLA LRA RLA LRA RLA LRA
10 31.0 239 28 239 14 125 10.9 80
11 33.4 245 30.2 245 15.1 125 12.7 100
13 39.8 300 36 300 18 150 15.6 109
15 47 340 42.5 340 21.2 110 18.6 132
TABLE 29 - ELECTRIC HEAT CAPACITY, MBH
ELECTRIC
HEAT KW
UNIT SUPPLY VOLTAGE
208/3/60 230/3/60 460/3/60 575/3/60
17.5 36.5 40.3 20.2 16.1
35 73.0 80.7 40.3 32.3
52.5 109.5 121.0 60.5 48.4
70 145.9 161.4 80.7 64.6
