Johnson Controls LSWU035 Engineering Guide

FORM 145.05-EG2 (618)
JOHNSON CONTROLS
23
TABLE 9 - LSWU032
AIR FLOW 12,800 CFM
EDB EWB
EWT 80 LWT 90 EWT 80 LWT 92 EWT 85 LWT 95
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
75 62 371 320 52.3 51.8 19.8 87.7 369 319 52.4 51.9 20.2 72.9 364 316 52.6 52.0 20.9 87.1
75 67 399 251 57.5 57.2 20.1 93.5 395 249 57.6 57.3 20.5 77.5 390 247 57.8 57.5 21.2 92.5
75 72 431 181 62.7 62.6 20.6 100.2 427 179 62.9 62.7 21.0 83.1 422 177 63.0 62.9 21.6 99.1
80 62 385 380 52.9 51.3 20.0 90.7 382 378 53.0 51.4 20.4 75.3 378 375 53.3 51.5 21.1 89.9
80 67 399 318 57.6 57.2 20.1 93.6 396 316 57.7 57.2 20.6 77.7 392 315 57.8 57.3 21.2 92.8
80 72 431 248 62.9 62.6 20.6 100.3 428 247 63.0 62.6 21.0 83.2 423 245 63.1 62.8 21.6 99.3
85 62 407 407 55.9 50.6 20.4 95.3 404 404 56.1 50.7 20.8 79.2 400 400 56.4 50.8 21.4 94.7
85 67 413 382 57.9 56.7 20.4 96.5 410 381 58.0 56.8 20.8 80.1 405 378 58.2 56.9 21.4 95.7
85 72 432 316 62.9 62.5 20.6 100.5 429 315 63.0 62.6 21.0 83.4 423 313 63.1 62.7 21.7 99.5
AIR FLOW 12,800 CFM
EDB EWB
EWT 85 LWT 97 EWT 90 LWT 100 EWT 90 LWT 102
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
75 62 362 315 52.7 52.1 21.3 72.4 357 313 52.8 52.2 22.0 86.4 355 311 52.9 52.3 22.5 71.9
75 67 387 246 57.8 57.5 21.6 76.8 382 244 58.0 57.7 22.3 91.5 378 243 58.0 57.8 22.7 76.0
75 72 418 176 63.1 62.9 22.0 82.3 412 174 63.2 63.1 22.7 97.9 409 173 63.3 63.2 23.2 81.3
80 62 375 374 53.3 51.6 21.5 74.8 370 370 53.6 51.8 22.2 89.2 368 368 53.8 51.8 22.7 74.2
80 67 388 313 57.9 57.5 21.6 77.0 383 311 58.1 57.6 22.3 91.9 379 310 58.1 57.7 22.8 76.2
80 72 419 244 63.2 62.9 22.1 82.4 414 242 63.3 63.0 22.7 98.3 410 241 63.4 63.1 23.2 81.5
85 62 398 398 56.6 50.9 21.9 78.7 393 393 56.9 51.0 22.6 94.0 391 391 57.1 51.1 23.0 78.2
85 67 402 377 58.3 57.0 21.9 79.5 397 374 58.5 57.2 22.6 94.9 394 373 58.5 57.2 23.1 78.7
85 72 420 311 63.3 62.8 22.1 82.6 415 309 63.4 62.9 22.7 98.4 411 308 63.5 63.0 23.2 81.7
HIGH EFFICIENCY - AIR FLOW 10,000 CFM
EDB EWB
EWT 80 LWT 90 EWT 80 LWT 92 EWT 85 LWT 95
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
75 62 377 298 48.1 48.0 19.9 89.0 374 296 48.3 48.2 20.3 73.9 370 294 48.5 48.4 20.9 88.2
75 67 407 239 53.8 53.7 20.3 95.2 404 237 54.0 53.9 20.7 79.0 398 235 54.2 54.1 21.3 94.3
75 72 440 181 59.4 59.3 20.8 102.3 437 180 59.5 59.4 21.2 84.9 431 178 59.7 59.6 21.8 101.2
80 62 390 356 47.7 47.6 20.1 91.6 387 355 47.8 47.7 20.5 76.1 382 353 47.9 47.8 21.2 90.9
80 67 408 296 53.5 53.4 20.3 95.4 405 294 53.7 53.6 20.7 79.3 399 292 53.8 53.7 21.3 94.4
80 72 442 237 59.2 59.1 20.8 102.6 438 236 59.3 59.2 21.2 85.0 432 234 59.5 59.4 21.8 101.4
85 62 406 406 47.9 47.0 20.4 95.2 404 404 48.0 47.0 20.8 79.1 400 400 48.4 47.2 21.5 94.6
85 67 419 355 53.0 52.9 20.5 97.7 416 353 53.1 53.0 21.0 81.2 411 351 53.3 53.2 21.6 96.9
85 72 442 294 58.9 58.8 20.8 102.7 439 292 59.1 59.0 21.2 85.2 433 290 59.2 59.1 21.8 101.5
HIGH EFFICIENCY - AIR FLOW 10,000 CFM
EDB EWB
EWT 85 LWT 97 EWT 90 LWT 100 EWT 90 LWT 102
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
75 62 367 293 48.5 48.4 21.4 73.3 362 290 48.8 48.7 22.1 87.4 359 289 48.9 48.8 22.5 72.6
75 67 395 234 54.2 54.1 21.7 78.1 390 232 54.4 54.3 22.4 93.2 386 230 54.6 54.5 22.9 77.4
75 72 428 176 59.7 59.7 22.2 84.0 422 174 60.0 59.9 22.9 100.1 418 173 60.1 60.0 23.4 83.0
80 62 380 351 48.1 48.0 21.6 75.6 375 349 48.3 48.2 22.3 90.1 372 347 48.5 48.4 22.8 74.9
80 67 396 291 53.9 53.8 21.8 78.4 391 289 54.1 54.0 22.5 93.6 388 287 54.3 54.2 23.0 77.7
80 72 429 233 59.5 59.4 22.2 84.2 423 230 59.8 59.7 22.9 100.3 419 229 59.9 59.8 23.4 83.2
85 62 396 396 48.8 47.4 21.9 78.5 392 392 49.1 47.6 22.6 93.9 389 389 49.4 47.7 23.1 78.0
85 67 408 350 53.4 53.3 22.0 80.5 403 347 53.7 53.6 22.7 96.0 400 346 53.8 53.7 23.2 79.8
85 72 430 289 59.3 59.2 22.3 84.2 423 287 59.5 59.4 22.9 100.3 420 285 59.7 59.6 23.4 83.3
NOTE: EDB-entering dry bulb temp, EWB-entering wet bulb temp, EWT-entering water temp, LWT-leaving water temp, LDB-leaving dry bulb temp,
LWB-leaving wet bulb temp, TMBH-total capacity, SMBH-sensible capacity
