Johnson Controls LSWU035 Engineering Guide

FORM 145.05-EG2 (618)
24
JOHNSON CONTROLS
TABLE 10 - LSWU035
AIR FLOW 14,000 CFM
EDB EWB
EWT 80 LWT 90 EWT 80 LWT 92 EWT 85 LWT 95
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
75 62 402 348 52.4 51.9 21.4 95.0 399 346 52.6 52.0 21.8 78.9 394 344 52.7 52.1 22.5 94.1
75 67 428 272 57.7 57.4 21.7 100.4 424 271 57.7 57.5 22.2 83.3 419 269 57.8 57.6 22.8 99.4
75 72 462 195 62.9 62.8 22.3 107.7 459 194 63.0 62.9 22.7 89.4 453 192 63.1 63.0 23.4 106.5
80 62 415 413 53.1 51.5 21.6 97.8 413 411 53.2 51.5 22.1 81.4 408 407 53.5 51.7 22.7 97.2
80 67 429 346 57.7 57.3 21.8 100.8 427 345 57.8 57.4 22.2 83.7 421 343 57.9 57.5 22.9 99.9
80 72 463 270 63.0 62.8 22.3 107.9 459 268 63.1 62.8 22.7 89.5 454 266 63.2 63.0 23.3 106.7
85 62 440 440 56.2 50.8 22.1 103.1 438 438 56.4 50.8 22.5 85.7 433 433 56.7 51.0 23.1 102.4
85 67 445 416 58.0 56.9 22.1 104.2 442 415 58.1 57.0 22.5 86.6 437 412 58.3 57.1 23.2 103.3
85 72 464 344 63.0 62.7 22.3 108.0 460 343 63.1 62.8 22.7 89.7 454 341 63.2 62.9 23.4 106.8
AIR FLOW 14,000 CFM
EDB EWB
EWT 85 LWT 97 EWT 90 LWT 100 EWT 90 LWT 102
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
75 62 391 342 52.8 52.2 22.9 78.2 386 340 52.9 52.3 23.7 93.4 383 338 53.1 52.4 24.2 77.6
75 67 415 267 58.0 57.7 23.3 82.4 410 265 58.1 57.9 24.0 98.3 406 264 58.2 58.0 24.5 81.6
75 72 449 190 63.2 63.1 23.8 88.4 443 188 63.4 63.3 24.5 105.3 439 187 63.4 63.3 25.0 87.4
80 62 405 405 53.6 51.8 23.2 80.8 401 401 53.9 51.9 23.9 96.6 398 398 54.0 52.0 24.4 80.3
80 67 419 342 58.0 57.6 23.3 83.1 414 339 58.2 57.7 24.1 99.1 411 338 58.2 57.8 24.6 82.4
80 72 450 265 63.3 63.0 23.8 88.5 444 263 63.4 63.2 24.5 105.5 440 261 63.5 63.3 25.0 87.5
85 62 430 430 56.9 51.0 23.6 85.1 425 425 57.2 51.2 24.3 101.6 422 422 57.4 51.3 24.8 84.4
85 67 434 410 58.4 57.2 23.6 85.7 429 408 58.5 57.3 24.3 102.3 425 406 58.7 57.4 24.8 85.0
85 72 451 339 63.3 63.0 23.8 88.7 445 337 63.5 63.1 24.5 105.7 441 336 63.5 63.2 25.0 87.7
HIGH EFFICIENCY - AIR FLOW 11,000 CFM
EDB EWB
EWT 80 LWT 90 EWT 80 LWT 92 EWT 85 LWT 95
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
75 62 406 323 48.5 48.4 21.4 95.8 402 321 48.7 48.6 21.9 79.5 398 319 48.8 48.7 22.5 94.9
75 67 435 258 54.2 54.1 21.9 101.9 431 256 54.4 54.3 22.3 84.6 425 254 54.5 54.4 23.0 100.8
75 72 472 194 59.7 59.7 22.5 109.7 468 193 59.9 59.8 22.9 91.0 462 191 60.0 59.9 23.5 108.4
80 62 419 387 48.0 47.9 21.7 98.5 416 386 48.1 48.0 22.1 81.8 411 383 48.4 48.3 22.8 97.7
80 67 437 321 53.8 53.7 21.9 102.4 433 319 54.0 53.9 22.3 84.9 428 317 54.2 54.1 23.0 101.3
80 72 472 256 59.6 59.5 22.5 109.8 468 255 59.6 59.5 22.9 91.1 462 252 59.9 59.8 23.5 108.5
85 62 438 438 48.6 47.3 22.1 102.6 435 435 48.8 47.4 22.5 85.2 430 430 49.2 47.6 23.1 101.9
85 67 450 385 53.4 53.3 22.2 105.2 447 384 53.5 53.4 22.6 87.4 441 381 53.7 53.6 23.3 104.1
85 72 473 318 59.3 59.2 22.5 109.9 469 317 59.4 59.3 22.9 91.2 463 315 59.5 59.4 23.5 108.6
HIGH EFFICIENCY - AIR FLOW 11,000 CFM
EDB EWB
EWT 85 LWT 97 EWT 90 LWT 100 EWT 90 LWT 102
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
75 62 394 317 49.0 48.9 23.0 78.8 390 315 49.1 49.0 23.7 94.1 386 313 49.3 49.2 24.2 78.1
75 67 422 252 54.7 54.6 23.4 83.7 417 250 54.8 54.7 24.1 99.8 412 248 55.0 54.9 24.6 82.7
75 72 458 189 60.2 60.1 24.0 89.9 452 187 60.4 60.3 24.7 107.1 448 185 60.4 60.4 25.1 88.9
80 62 407 382 48.4 48.3 23.3 81.1 402 379 48.7 48.6 24.0 96.8 399 377 48.9 48.8 24.5 80.4
80 67 425 315 54.3 54.2 23.5 84.1 419 313 54.5 54.4 24.2 100.3 416 312 54.6 54.5 24.7 83.3
80 72 459 251 60.0 59.9 24.0 90.1 453 249 60.1 60.0 24.7 107.4 448 247 60.3 60.2 25.2 89.0
85 62 427 427 49.5 47.7 23.6 84.6 422 422 49.9 47.9 24.3 101.1 419 419 50.2 48.0 24.8 84.0
85 67 438 380 53.8 53.7 23.7 86.6 433 377 54.0 53.9 24.4 103.3 430 376 54.1 54.0 24.9 85.8
85 72 459 313 59.7 59.6 24.0 90.2 453 311 59.9 59.8 24.7 107.4 449 310 59.9 59.8 25.2 89.2
NOTE: EDB-entering dry bulb temp, EWB-entering wet bulb temp, EWT-entering water temp, LWT-leaving water temp, LDB-leaving dry bulb temp,
LWB-leaving wet bulb temp, TMBH-total capacity, SMBH-sensible capacity
Cooling Performance Data (Cont’d)
