Johnson Controls LSWU035 Engineering Guide

FORM 145.05-EG2 (618)
JOHNSON CONTROLS
25
TABLE 11 - LSWU040
AIR FLOW 16,000 CFM
EDB EWB
EWT 80 LWT 90 EWT 80 LWT 92 EWT 85 LWT 95
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
75 62 454 399 52.4 52.0 23.4 106.7 451 398 52.4 52.1 23.9 88.7 445 395 52.6 52.2 24.6 105.8
75 67 479 311 57.7 57.6 23.8 112.0 475 309 57.7 57.7 24.3 93.0 469 307 58.0 57.9 25.0 110.9
75 72 517 221 63.1 63.0 24.7 120.3 513 219 63.1 63.1 25.1 99.8 507 217 63.3 63.2 25.8 119.0
80 62 473 473 53.0 51.5 23.8 110.9 470 470 53.2 51.6 24.3 92.1 465 465 53.5 51.7 25.0 110.0
80 67 488 399 57.5 57.4 24.1 114.1 485 397 57.6 57.4 24.5 94.7 479 394 57.8 57.6 25.2 113.0
80 72 518 308 63.1 63.0 24.7 120.4 514 307 63.1 63.0 25.1 100.0 508 305 63.2 63.1 25.8 119.2
85 62 500 500 56.4 50.8 24.3 116.7 497 497 56.6 50.9 24.8 97.0 492 492 56.9 51.0 25.5 115.8
85 67 503 482 57.6 57.0 24.4 117.3 500 480 57.8 57.1 24.9 97.4 494 477 57.9 57.2 25.6 116.2
85 72 524 398 62.8 62.7 24.8 121.8 520 396 62.9 62.8 25.3 101.1 514 394 63.0 62.9 26.0 120.6
AIR FLOW 16,000 CFM
EDB EWB
EWT 85 LWT 97 EWT 90 LWT 100 EWT 90 LWT 102
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
75 62 442 394 52.6 52.3 25.1 87.9 436 391 52.8 52.5 25.9 104.9 432 389 52.9 52.6 26.4 87.1
75 67 465 306 58.0 57.9 25.5 92.0 459 303 58.1 58.1 26.3 109.7 455 302 58.2 58.1 26.8 91.0
75 72 503 216 63.4 63.3 26.3 98.7 496 213 63.5 63.5 27.0 117.6 491 212 63.6 63.5 27.6 97.6
80 62 462 462 53.6 51.8 25.5 91.4 457 457 53.9 51.9 26.3 109.2 453 453 54.2 52.0 26.8 90.7
80 67 475 393 57.8 57.7 25.7 93.9 469 390 58.0 57.8 26.5 111.9 465 388 58.1 57.9 27.1 92.9
80 72 504 303 63.2 63.2 26.3 98.9 497 301 63.4 63.3 27.1 117.8 492 299 63.6 63.5 27.6 97.7
85 62 489 489 57.0 51.1 26.0 96.3 483 483 57.4 51.2 26.8 115.0 480 480 57.6 51.3 27.4 95.5
85 67 491 475 58.0 57.3 26.1 96.6 484 472 58.2 57.4 26.8 115.2 481 470 58.3 57.5 27.4 95.7
85 72 510 392 63.2 63.1 26.5 100.1 504 390 63.3 63.2 27.2 119.4 500 388 63.3 63.2 27.8 99.1
HIGH EFFICIENCY - AIR FLOW 13,000 CFM
EDB EWB
EWT 80 LWT 90 EWT 80 LWT 92 EWT 85 LWT 95
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
75 62 455 370 49.3 49.2 23.4 107.0 452 369 49.4 49.3 23.9 88.9 446 366 49.4 49.3 24.6 106.0
75 67 483 292 55.1 55.0 23.9 113.0 479 291 55.1 55.0 24.4 93.8 474 288 55.1 55.0 25.1 111.9
75 72 523 217 60.6 60.5 24.8 121.6 519 216 60.7 60.6 25.2 100.9 513 214 60.7 60.6 25.9 120.3
80 62 469 447 48.7 48.6 23.7 110.1 467 446 48.8 48.7 24.2 91.5 461 443 48.8 48.7 24.9 109.2
80 67 490 368 54.6 54.5 24.1 114.4 487 367 54.7 54.6 24.6 95.1 480 364 54.7 54.6 25.3 113.3
80 72 524 290 60.4 60.3 24.8 121.7 520 289 60.5 60.4 25.3 101.0 513 287 60.5 60.4 25.9 120.3
85 62 494 494 50.2 48.1 24.2 115.4 491 491 50.4 48.2 24.7 95.8 485 485 50.4 48.2 25.4 114.4
85 67 505 445 54.1 54.0 24.4 117.7 501 443 54.2 54.1 24.9 97.7 495 441 54.2 54.1 25.6 116.5
85 72 527 365 60.0 59.9 24.9 122.4 523 364 60.1 60.0 25.3 101.6 517 361 60.1 60.0 26.0 121.1
HIGH EFFICIENCY - AIR FLOW 13,000 CFM
EDB EWB
EWT 85 LWT 97 EWT 90 LWT 100 EWT 90 LWT 102
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
75 62 443 365 49.6 49.5 25.1 88.1 437 362 49.8 49.7 25.9 105.1 434 360 50.0 49.9 26.4 87.3
75 67 470 287 55.4 55.3 25.6 92.8 463 284 55.6 55.5 26.4 110.7 459 283 55.7 55.6 26.9 91.8
75 72 509 212 61.0 60.9 26.4 99.8 501 210 61.1 61.0 27.2 118.8 497 208 61.2 61.1 27.7 98.6
80 62 457 441 49.2 49.1 25.4 90.7 451 438 49.4 49.3 26.2 108.1 448 437 49.4 49.3 26.8 89.9
80 67 477 362 55.0 54.9 25.8 94.1 470 360 55.2 55.1 26.6 112.2 467 358 55.3 55.2 27.1 93.2
80 72 509 285 60.7 60.6 26.4 99.9 503 283 60.9 60.8 27.2 119.1 498 281 61.0 60.9 27.7 98.7
85 62 482 482 51.1 48.4 25.9 95.1 477 477 51.4 48.6 26.7 113.6 473 473 51.7 48.7 27.3 94.4
85 67 492 439 54.5 54.4 26.1 96.8 485 436 54.7 54.6 26.9 115.4 482 435 54.8 54.7 27.4 95.8
85 72 513 360 60.4 60.3 26.5 100.5 506 357 60.6 60.5 27.3 119.9 502 356 60.6 60.5 27.8 99.5
NOTE: EDB-entering dry bulb temp, EWB-entering wet bulb temp, EWT-entering water temp, LWT-leaving water temp, LDB-leaving dry bulb temp,
LWB-leaving wet bulb temp, TMBH-total capacity, SMBH-sensible capacity
