Johnson Controls LSWU035 Engineering Guide

FORM 145.05-EG2 (618)
26
JOHNSON CONTROLS
TABLE 12 - LSWU050
AIR FLOW 20,000 CFM
EDB EWB
EWT 80 LWT 90 EWT 80 LWT 92 EWT 85 LWT 95
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
75 62 572 503 52.2 51.9 28.4 133.7 567 500 52.3 52.0 29.0 111.0 560 497 52.4 52.2 29.9 132.5
75 67 607 392 57.6 57.5 28.8 141.0 601 390 57.7 57.6 29.4 117.0 593 387 57.8 57.7 30.3 139.3
75 72 656 279 62.9 62.9 29.5 151.3 651 277 63.0 63.0 30.0 125.5 642 274 63.1 63.1 30.9 149.4
80 62 596 596 52.8 51.4 28.6 138.7 592 592 53.0 51.5 29.2 115.3 586 586 53.3 51.6 30.1 137.7
80 67 613 503 57.4 57.3 28.9 142.2 608 501 57.5 57.4 29.5 118.1 601 497 57.6 57.5 30.4 140.9
80 72 657 389 62.9 62.8 29.5 151.6 651 387 63.0 62.9 30.1 125.6 642 384 63.1 63.0 31.0 149.6
85 62 632 632 56.1 50.7 29.0 146.1 627 627 56.3 50.8 29.6 121.3 620 620 56.6 50.9 30.5 144.9
85 67 637 604 57.6 56.9 29.1 147.3 632 602 57.7 56.9 29.7 122.2 624 598 57.8 57.1 30.6 145.6
85 72 659 499 62.8 62.7 29.5 151.9 653 497 62.8 62.7 30.1 125.9 644 494 63.0 62.9 31.0 150.0
AIR FLOW 20,000 CFM
EDB EWB
EWT 85 LWT 97 EWT 90 LWT 100 EWT 90 LWT 102
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
75 62 555 494 52.6 52.3 30.5 109.9 548 490 52.7 52.4 31.5 131.2 543 488 52.8 52.5 32.1 108.8
75 67 588 385 57.9 57.8 30.9 115.6 580 381 58.0 58.0 31.9 137.7 574 379 58.2 58.1 32.5 114.2
75 72 636 272 63.3 63.2 31.6 124.0 627 269 63.4 63.3 32.5 147.5 622 267 63.5 63.4 33.1 122.4
80 62 581 581 53.5 51.7 30.7 114.4 574 574 53.8 51.9 31.8 136.5 570 570 54.0 51.9 32.4 113.4
80 67 596 495 57.7 57.6 31.0 117.0 589 492 57.8 57.7 32.0 139.7 584 490 57.9 57.8 32.7 115.9
80 72 638 382 63.2 63.1 31.5 124.2 628 379 63.3 63.2 32.5 147.8 622 377 63.4 63.3 33.1 122.5
85 62 616 616 56.8 51.0 31.1 120.4 608 608 57.2 51.2 32.1 143.5 604 604 57.4 51.2 32.8 119.3
85 67 619 595 58.0 57.2 31.2 120.9 611 591 58.2 57.3 32.2 144.3 607 589 58.2 57.4 32.8 119.8
85 72 639 492 63.1 63.0 31.5 124.5 630 489 63.2 63.1 32.5 148.3 625 487 63.3 63.2 33.2 123.1
HIGH EFFICIENCY - AIR FLOW 16,000 CFM
EDB EWB
EWT 80 LWT 90 EWT 80 LWT 92 EWT 85 LWT 95
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
75 62 569 462 48.9 48.8 28.3 133.2 565 460 49.0 48.9 28.9 110.7 558 457 49.2 49.1 29.8 132.0
75 67 612 367 54.7 54.6 28.9 142.0 607 365 54.8 54.7 29.5 117.9 599 362 54.9 54.8 30.3 140.5
75 72 664 275 60.2 60.1 29.5 152.9 658 273 60.3 60.2 30.1 126.7 649 269 60.5 60.4 31.0 150.9
80 62 592 557 48.4 48.3 28.5 137.8 587 555 48.5 48.4 29.1 114.3 579 551 48.7 48.6 30.0 136.3
80 67 615 459 54.3 54.2 28.9 142.7 609 457 54.4 54.3 29.5 118.3 602 454 54.5 54.4 30.4 141.1
80 72 664 365 60.0 59.9 29.5 153.0 658 363 60.1 60.0 30.1 126.8 650 360 60.2 60.1 31.0 151.1
85 62 621 621 49.5 47.7 28.8 143.9 617 617 49.7 47.8 29.4 119.5 610 610 50.1 48.0 30.3 142.7
85 67 634 554 53.7 53.6 29.1 146.7 629 552 53.8 53.7 29.6 121.8 622 549 54.0 53.9 30.5 145.3
85 72 666 456 59.7 59.6 29.6 153.3 660 454 59.8 59.7 30.1 127.2 652 451 59.9 59.8 31.0 151.5
HIGH EFFICIENCY - AIR FLOW 16,000 CFM
EDB EWB
EWT 85 LWT 97 EWT 90 LWT 100 EWT 90 LWT 102
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
75 62 553 454 49.4 49.3 30.5 109.6 546 451 49.5 49.4 31.4 130.8 542 449 49.6 49.5 32.1 108.5
75 67 593 359 55.1 55.0 30.9 116.4 585 356 55.3 55.2 31.9 138.8 579 354 55.4 55.3 32.6 115.0
75 72 644 268 60.6 60.5 31.6 125.2 634 264 60.8 60.7 32.5 148.9 628 262 60.9 60.8 33.2 123.5
80 62 574 549 48.8 48.7 30.6 113.2 567 545 49.0 48.9 31.6 134.9 562 542 49.2 49.1 32.3 112.0
80 67 597 452 54.7 54.6 31.0 117.1 588 448 54.9 54.8 32.0 139.4 582 446 55.0 54.9 32.6 115.6
80 72 644 358 60.3 60.2 31.6 125.4 635 354 60.6 60.5 32.5 149.2 629 352 60.7 60.6 33.2 123.7
85 62 606 606 50.4 48.1 31.0 118.5 598 598 50.8 48.3 31.9 141.4 594 594 51.0 48.4 32.6 117.5
85 67 617 546 54.2 54.1 31.1 120.6 609 543 54.3 54.2 32.1 143.7 604 540 54.5 54.4 32.8 119.3
85 72 646 449 60.0 59.9 31.6 125.6 637 446 60.2 60.1 32.6 149.6 630 443 60.4 60.3 33.2 123.9
NOTE: EDB-entering dry bulb temp, EWB-entering wet bulb temp, EWT-entering water temp, LWT-leaving water temp, LDB-leaving dry bulb temp,
LWB-leaving wet bulb temp, TMBH-total capacity, SMBH-sensible capacity
Cooling Performance Data (Cont’d)

Johnson Controls LSWU035 Specifications

General

Brand	Johnson Controls
Model	LSWU035
Category	Chiller
Language	English
