Johnson Controls Metasys DX-9100 User Manual

Metasys Ventilation Controller Application for the DX-9100
15
Sampling
DX-9100
3-Way
Valves
CO
Sensor
2
Ports for Outside,
Return, and Supply Air
To Air Sampling
Location 1
To Air Sampling
Location 3
Air Sampling
Device
Direction
of Flow
Air Sampling
Location 2
Air Filter
Air Pump
Figure 3: Air Sampling Device Installation
8. Open the enclosure cover and remove the packing material.
9. Remove the tie-wrap from the air pump.
Trending Data
To trend outdoor air flow and CO
2
values for this application, consult
the appropriate workstation user’s manual.
Some of the points that may be trended are:
• outdoor air CO
2
concentration
• return air CO
2
concentration
• supply air CO
2
concentration
• supply air flow (measured)
• outdoor air flow (calculated)

Johnson Controls Metasys DX-9100 Specifications

General

Brand	Johnson Controls
Model	Metasys DX-9100
Category	Controller
Language	English
