Johnson Controls Metasys DX-9100 User Manual

Metasys Ventilation Controller Application for the DX-9100
5
Key Concepts
Johnson Controls CO
2
Concentration Samplers
Johnson Controls offers two 3-point, multiplexed CO
2
measurement
devices, as shown in Table 1.
Table 1: Attributes of the MVC-2000-1
Product Intended Use Enclosure Controller Software Links
MVC-2000-1
3-point,
multiplexed CO
2
measurement
UPM
Enclosure
One
Metasys
Extended
Digital
Controller
(DX-9100)
GX-9100 Application
for MVC is
pre-installed in the
DX-9100.
Metasys
Supervisory
Controller and
workstation links
possible but not
required.
This document gives procedures that are unique to the MVC-2000-1
and its components as shown in Figure 1. Refer to existing product
documentation for standard procedures involving these components.
MVC-2000-1 Package
Many of the components of the MVC-2000-1 package are
Johnson Controls products, including the:
• UPM
• DX-9100, Version 2.4 or later
• GX-9100 Configuration Tool Software for the DX-9100
• V11HGA-100 3-way Solenoid Air Valve
• A-4000-137 Air Filter
