Johnson Controls Metasys DX-9100 User Manual

Metasys Ventilation Controller
6
Mvc2000B
DX-9100
3-Way
Valves
CO
Sensor
2
Ports for Outside,
Return, and Supply Air
Air Filter
Air Pump
Figure 1: Components of an MVC-2000-1
Universal Packaging Module (UPM)
The MVC-2000-1 product line utilizes the EN-EWC35-0 UPM. Each
EWC number ends with a “5,” which means that the UPM enclosure
with cover also comes equipped with a transformer and a power box.
Refer to the UPM literature for the following UPM procedures:
• engineering
• installation, which includes:
a. mounting
b. landing conduit
c. power connections
d. grounding and bonding
• commissioning
