Metasys Ventilation Controller Application for the DX-9100
7
DX-9100
The DX-9100 is a controller manufactured and marketed by
Johnson Controls. The Metasys Ventilation Controller Application of
the GX-9100 Software Tool is used to program the DX-9100.
DX-9100 Hardware
The MVC-2000-1 product utilizes one DX-9100. The DX-9100 is
factory installed in the MVC-2000-1.
!
CAUTION: Do not use any additional inputs or outputs on
the DX-9100, which is performing the outdoor
air flow calculations. The GX-9100 software
uses the full capabilities of the controller and
adding additional inputs or outputs risks
overburdening the system.
GX-9100 Software Configuration Tool
To use the MVCA, it is necessary to know GX-9100 basics such as:
• opening a file
• downloading a file
• commissioning a DX-9100
These procedures are contained in the GX-9100 Software
Configuration Tool User’s Guide (LIT-6364060).
GX-9100 Application for MVC
The MVCA is factory downloaded into the DX-9100.
For an explanation of the GX-9100 application for MVCA, refer to the
Metasys Ventilation Controller Application (MVCA) Application Note
(LIT-653435).
CO
2
Sensor
Each MVC-2000-1 contains a single CO
2
sensor. It is used to sense the
CO
2
levels in three distinct airstreams:
• supply air
• return air
• outdoor air
This is achieved through the use of two 3-way pneumatic valves and
the associated multiplexing control. Three separate pneumatic lines
are multiplexed into the single CO
2
sensor.
