54 VAV Controller—Variable Air Volume Controller
Point
Type
(Cont.)
Point
Name
HVAC PRO for Windows
Configuration
Assignments and Defaults
HVAC PRO for Windows
Configuration Options
Binary
BO 1 Supply Damper Open None
Outputs
BO 2 Supply Damper Close None
BO 3 Parallel and Series On-Off Fans None
Exhaust Box Open Unused
Unused Rename
BO 4 Exhaust Box Close None
Baseboard Heat On-Off None
First Stage Box Heat*** None
Unused Rename
BO 5 Baseboard Incremental Open None
Box Heat Incremental Open None
First Stage Box Heat** None
Second Stage Box Heat*** None
Lights On for VAV101 None
Unused Rename
BO 6 Baseboard Incremental Close None
Box Heat Incremental Close None
On-Off/Single Stage Box Heat None
Second Stage Box Heat** None
Third Stage Box Heat*** None
Lights Off for VAV101 None
Unused Rename
BO 7 Baseboard Incremental Open
on VAV100
None
Lights On for VAV100 None
Unused Rename
BO 8 Baseboard Incremental Close
on VAV100
None
Lights Off for VAV100 None
Unused Rename
Analog
Outputs
AO 1 S66 Output for
Proportional Series Fan
None
Unused Rename
AO 2 Proportional Box Heat None
Unused Rename
** 2-Stages Box Heat
*** 3-Stages Box Heat
