SECTION 2 - OPERATION
FORM 145.10-IOM4
ISSUE DATE: 2/27/2019
2
SECTION 2 - OPERATION
SINGLE STAGE WIRING INTERCONNECTION
This applies to DSH024–060B/C and DSV060B/C models.
PRESSURE CONTROL PANEL
C450CPN-4
Controller
M9108 Actuator
BLACK
RC
V
RED
WHITE
5V
SN1 C
BLACK
WHITE
RED
WHA-PKD3-200C
WIRING HARNESS
P499/P598 TRANSDUCER
R
C
24VA01
BLACK
WHITE
RED
123456
RED
WHITE
LADK-WHA-03
WHO20
WHO20
LADK-WHA-01
Option 2: Power Supply Connection
from SE Controller Unit
WHITE
RED
Option 1: Power Supply Connection
from Simplicity Lite Unit
X2H2
X1H1
TRF
ISOLATED MALE
1/4-INCH Q.C.
ISOLATED MALE
1/4-INCH Q.C.
G
W1 Y1
OCC
X
R
SD C
MB
LD26869
FIGURE 12 - SINGLE COMPRESSOR APPLICATION
