Johnson Controls R-410A User Manual

16
FORM 145.10-IOM4
ISSUE DATE: 2/27/2019
SECTION 1 - INSTALLATION
DUAL STAGE WIRING INTERCONNECTION
This applies to DSH096–120B/C and DSV096–300B/C models.
PRESSURE CONTROL PANEL
C450CPN-4
Controller
M9108 Actuator
BLACK
RC
V
RED
WHITE
5VSN1C
BLACK
WHITE
RED
WHA-PKD3-200C
WIRING HARNESS
P499/P598 TRANSDUCER
R
C
24VA01
BLACK
WHITE
RED
123456
RED
WHITE
LADK-WHA-03
WHO20
WHO20
LADK-WHA-01
Option 2: Power Supply Connectionfrom SE Controller Unit
WHITE
RED
Option 1: Power Supply Connection from Simplicity 1A Unit
X2 H2
X1
H1
TRF
ISOLATED MALE
1/4-INCH Q.C.
ISOLATED MALE
1/4-INCH Q.C.
G
W1
Y1
OCC
X
R
SD
C
MB
WHITE
RED
W2
Y2
LD26870
FIGURE 13 - DUAL COMPRESSOR APPLICATION
