Johnson Controls RBS009 User Manual

27
RB SERIES ENGINEERING GUIDE
Vertical Dimensional Data cont.
Vertical Models LL
015-018 15.8 [40.1]
024-030 18.8 [47.8]
036 15.3 [38.9]
042-048 13.8 [35.1]
060 14.3 [36.3]
070 14.3 [36.3]
Dimensions in inches [cm]
* Models 006-012 - Externally Mounted Disconnect
**UBV-041 - Disconnect not available
V
ertical Disconnect
When using disconnect, do not use dimension L from the standard
vertical dimensional data. Use dimension LL from the vertical
disconnect dimensional data.
Vertical
Models
Overall Cabinet Water Connections
Electrical Knockouts
678
12 5 J K L
ABCDEHLoop 1/2” cond 1/2” cond 1” cond M
Width Depth Height* In Out Condensate Water FPT
Low
Voltage
Low
Voltage
Power Sup-
ply
Filter Rack
Width
006-012
in. 19.2 19.2 24.2 2.6 5.6 8.8 1/2” 7.4 3.4 5.4 2.2
cm. 48.8 48.8 61.5 6.6 14.2 22.4 12.7 mm 18.8 8.6 13.7 5.6
015-018
in. 22.5 22.2 30.2 2.6 7.6 10.8 3/4” 9.4 5.4 7.4 2.2
cm. 57.2 56.4 76.7 6.6 19.3 27.4 19.1 mm 23.9 13.7 18.8 5.6
024-030
in. 22.5 22.2 36.2 2.6 7.6 10.8 3/4” 9.4 5.4 7.4 2.2
cm. 57.2 56.4 91.9 6.6 19.3 27.4 19.1 mm 23.9 13.7 18.8 5.6
036
in. 22.5 26.2 40.2 2.6 7.6 10.8 3/4” 10.1 6.1 8.1 2.2
cm. 57.2 66.5 102.1 6.6 19.3 27.4 19.1 mm 25.7 15.5 20.6 5.6
041
in. 21.5 21.5 40.2 2.6 7.6 10.8 3/4” 9.4 5.4 7.4 1.2
cm. 54.6 54.6 102.1 6.6 19.3 27.4 19.1 mm 23.9 13.7 18.8 3.0
042-048
in. 22.5 26.2 44.2 2.6 7.6 10.8 3/4” 10.1 6.1 8.1 2.2
cm. 57.2 66.5 112.3 6.6 19.3 27.4 19.1 mm 25.7 15.5 20.6 5.6
060
in. 25.5 31.2 44.2 2.6 7.6 10.8 1” 10.1 6.1 8.1 2.2
cm. 64.8 79.2 112.3 6.6 19.3 27.4 25.4 mm 25.7 15.5 20.6 5.6
070
in. 25.5 31.2 48.2 2.6 7.6 10.8 1” 10.1 6.1 8.1 2.2
cm. 64.8 79.2 122.4 6.6 19.3 27.4 25.4 mm 25.7 15.5 20.6 5.6
Vertical
Models
Discharge Connection
duct fl ange installed (±0.10 in)
**Return Connection
using deluxe fi lter rack (±0.10 in)
NPQRSTUVW
Supply Width Supply Depth Return Depth Return Height
006-012
in. 10.0 10.0 4.6 4.4 7.8 2.4 14.3 10.1 2.0
cm. 25.4 25.4 11.7 11.2 19.8 6.1 36.3 25.7 5.1
015-018
in. 14.0 14.0 4.1 4.3 7.7 2.1 18.1 14.0 2.0
cm. 35.6 35.6 10.4 10.9 19.6 5.3 46.0 35.6 5.1
024-030
in. 14.0 14.0 4.1 4.3 7.7 2.1 18.1 20.0 2.0
cm. 35.6 35.6 10.4 10.9 19.6 5.3 46.0 50.8 5.1
036
in. 14.0 14.0 6.1 4.5 7.7 2.1 22.1 22.1 2.0
cm. 35.6 35.6 15.5 11.4 19.6 5.3 56.1 56.1 5.1
041
in. 14.0 14.0 3.8 3.5 6.7 0.6 20.2 28.0 0.6
cm. 35.6 35.6 9.7 8.9 17.0 1.5 51.3 71.1 1.5
042-048
in. 18.0 18.0 4.1 2.1 3.9 2.1 22.1 26.1 2.0
cm. 45.7 45.7 10.4 5.3 9.9 5.3 56.1 66.3 5.1
060
in. 18.0 18.0 6.6 4.6 6.3 1.6 28.1 26.0 2.0
cm. 45.7 45.7 16.8 11.7 16.0 4.1 71.4 66.0 5.1
070
in. 18.0 18.0 6.6 4.6 6.3 1.6 28.1 30.0 2.0
cm. 45.7 45.7 16.8 11.7 16.0 4.1 71.4 76.2 5.1
Condensate is 3/4” PVC female glue socket and is switchable from side to front. 10/15/15
*Discharge fl ange is fi eld installed and extends 1” (25.4 mm) from top of cabinet.
**Vertical units shipped with standard 2” (fi eld adjustable to 1”) open application fi lter rack extending 2.2” from unit and is not suitable for duct connection.
For ductable return connection applications, order the deluxe 2” (fi eld adjustable to 1”) duct collar/fi lter rack which extends 3.25
