RB SERIES ENGINEERING GUIDE
Electrical Availability
PSC
Voltage
Single Speed Models
006 009 012 015 018 024 030 036 041 042 048 060 070
115/60/1 ●●●
208-230/60/1 ●●●●●●●●●●●●●
265/60/1 ●●●●●●●●
208-230/60/3 ●●●●●●●●
460/60/3 ●●●●●●●●
575/60/3 ●●●●●
10/15/15
Variable Speed ECM
Voltage
Single Speed Models
006 009 012 015 018 024 030 036 041 042 048 060 070
208-230/60/1 ●●●●●●●●●●
265/60/1 ●●●●●
208-230/60/3 ●●●●●●●●
460/60/3 ●●●●●●●●
575/60/3
10/15/15
5 Speed ECM
Voltage
Single Speed Models
006 009 012 015 018 024 030 036 041 042 048 060 070
208-230/60/1 ●●●●●●●●●●
265/60/1 ●●●●●
208-230/60/3 ●●●●●●●●
460/60/3 ●●●●●●●●
575/60/3
10/15/15
