29
RB SERIES ENGINEERING GUIDE
Horizontal Dimensional Data cont.
Horizontal Models KK
015-018 8.2 [20.8]
024-030 8.2 [20.8]
036 9.2 [23.4]
042-048 9.2 [23.4]
060 11.2 [28.4]
070 10.2 [25.9]
Dimensions in inches [cm]
* Models 006-012 - Externally Mounted Disconnect
Horizontal Disconnect
When using disconnect, do not use dimension K from the standard
horizontal dimensional data. Use dimension KK from the horizontal
disconnect dimensional data.
Horizontal
Models
Overall Cabinet
Water Connections Electrical Knockouts
123
Loop
JK
A B C D E H 1/2 in. cond 1 in. cond
Width Depth Height* In Out Condensate Water FPT Low Voltage Power Supply
006-012**
in. 19.2 35.0 12.1 1.8 4.8 3.6 1/2 in. 7.4 7.5
cm. 48.8 88.9 30.7 4.6 12.2 9.1 12.70 mm 18.8 19.1
015-018
in. 22.5 35.0 17.2 1.8 6.8 0.8 3/4 in. 7.1 7.1
cm. 57.2 88.9 43.7 4.6 17.3 2.0 19.05 mm 18.0 18.0
024-030
in. 22.5 42.0 17.2 1.8 6.8 0.8 3/4 in. 7.1 7.1
cm. 57.2 106.7 43.7 4.6 17.3 2.0 19.05 mm 18.0 18.0
036
in. 22.5 42.0 19.2 1.8 6.8 0.8 3/4 in. 9.2 7.1
cm. 57.2 106.7 48.8 4.6 17.3 2.0 19.05 mm 23.4 18.0
042-048
in. 22.5 45.0 19.2 1.8 6.8 0.8 3/4 in. 9.2 7.1
cm. 57.2 114.3 48.8 4.6 17.3 2.0 19.05 mm 23.4 18.0
060
in. 25.5 48.0 21.2 1.8 6.8 0.8 1 in. 9.2 9.1
cm. 64.8 121.9 53.8 4.6 17.3 2.0 25.4 mm 23.4 23.1
070
in. 25.5 53.0 21.2 1.8 6.8 0.8 1 in. 9.2 9.1
cm. 64.8 134.6 53.8 4.6 17.3 2.0 25.4 mm 23.4 23.1
Horizontal
Models
Discharge Connection
duct fl ange installed (±0.10 in)
Return Connection
using deluxe fi lter rack option (±0.10 in)
PVC Size
LMNPQRSTX
Supply Width Supply Depth Return Depth Return Height
006-012**
in. 2.3 8.0 10.0 2.7 22.5 9.4 2.4 1.4 1/2 in.
cm. 5.8 20.3 25.4 6.9 57.2 23.9 6.1 3.6 1.3
015-018
in. 5.7 10.5 9.4 4.9 16.4 14.5 2.0 1.4 3/4 in.
cm. 14.5 26.7 23.9 12.4 41.7 36.8 5.1 3.6 1.9
024-030
in. 5.7 10.5 9.4 4.9 23.4 14.5 2.0 1.4 3/4 in.
cm. 14.5 26.7 23.9 12.4 59.4 36.8 5.1 3.6 1.9
036
in. 6.7 10.5 9.4 4.9 27.4 16.5 2.0 1.4 3/4 in.
cm. 17.0 26.7 23.9 12.4 69.6 41.9 5.1 3.6 1.9
042-048
in. 4.2 13.6 13.2 2.4 30.4 16.5 2.0 1.5 3/4 in.
cm. 10.7 34.5 33.5 6.1 77.2 41.9 5.1 3.8 1.9
060
in. 4.8 13.6 13.2 4.6 35.4 18.7 2.3 1.3 3/4 in.
cm. 12.2 34.5 33.5 11.7 89.9 47.5 5.8 3.3 1.9
070
in. 4.8 13.6 13.2 4.6 40.4 18.5 2.3 1.4 3/4 in.
cm. 12.2 34.5 33.5 11.7 102.6 47.0 5.8 3.6 1.9
09/26/12
Horizontal units shipped with standard 2 in. (fi eld adjustable to 1 in.) open application fi lter rail extending 2.2 in. from the unit and is not
suitable for duct connection. For ductable return connection applications, order the 2 in. (fi eld adjustable to 1 in.) duct collar/fi lter rack which
extends to 3.25 in. from the unit and is suitable for duct connections.
** H006-012 offers a lifted drain pan that allows the trap to be installed without additional ceiling height required.
