Johnson Controls RBS009 User Manual

44
RB SERIES ENGINEERING GUIDE
Pressure Drop
Model GPM
Pressure Drop (psi)
Valve GPM Cv
Pressure
30°F 50°F 70°F 90°F 110°F Drop (psi)
006
1.0 1.2 1.2 1.1 1.0 1.0
Internally mounted 2-position solenoid water valves are not
available on models 006-012
1.5 2.2 2.0 1.9 1.8 1.7
2.0 3.3 3.1 2.9 2.7 2.5
2.5 4.1 3.8 3.4 3.1 2.9
009
1.5 1.9 1.7 1.5 1.3 1.1
2.0 3.0 2.8 2.6 2.4 2.2
3.0 6.3 6.3 6.1 5.9 5.7
4.0 8.1 7.9 7.4 6.8 6.1
012
1.5 1.1 1.1 1.0 0.9 0.9
2.5 2.4 2.3 2.2 2.0 1.9
3.5 4.2 4.0 3.7 3.4 3.2
4.5 6.1 5.9 5.2 4.7 4.1
015
2.0 1.8 1.7 1.6 1.4 1.2
1/2”
3.0
9.9 0.09
3.0 3.3 3.1 2.9 2.6 2.3 4.0 10.1 0.16
4.0 5.0 4.9 4.8 4.7 4.6 5.0 10.4 0.23
5.0 7.1 6.7 5.9 5.4 5.1 6.0 10.6 0.32
018
3.0 3.3 3.2 3.0 2.8 2.6
1/2”
3.0
9.9 0.09
4.0 4.7 4.2 3.9 3.6 3.1 4.0 10.1 0.16
5.0 6.2 5.2 4.7 4.1 3.5 5.0 10.4 0.23
6.0 7.7 6.2 5.4 4.6 3.8 6.0 10.6 0.32
024
3.0 3.2 3.1 2.9 2.7 2.5
3/4”
3.0
9.9 0.09
4.5 6.1 5.5 4.9 4.5 4.2 4.5 10.2 0.19
6.0 9.0 7.9 6.9 6.3 5.8 6.0 10.6 0.32
8.0 12.9 10.9 9.5 8.8 7.9 8.0 11.0 0.53
030
4.0 2.4 2.3 2.2 2.0 1.8
3/4”
4.0
10.1 0.16
6.0 5.1 4.9 4.7 4.5 4.3 6.0 10.6 0.32
8.0 7.8 7.5 7.1 6.9 6.7 8.0 11.0 0.53
10.0 10.5 10.1 9.6 9.3 8.9 10.0 11.5 0.76
036
5.0 2.0 1.9 1.7 1.5 1.4
3/4”
5.0
10.4 0.23
7.0 3.6 3.5 3.3 3.1 2.9 7.0 10.8 0.42
9.0 5.2 5.1 4.8 4.6 4.4 9.0 11.2 0.64
12.0 7.5 7.4 7.1 6.9 6.7 12.0 11.9 1.02
041
5.0 1.5 1.2 0.9 0.5 0.4
N/A
8.0 3.4 3.1 2.8 2.5 2.1
11.0 7.9 7.5 7.2 6.9 6.6
14.0 9.1 8.8 8.5 8.2 7.9
042
5.0 2.1 2.0 1.8 1.6 1.4
3/4”
5.0
10.4 0.23
8.0 4.8 4.7 4.5 4.4 4.2 8.0 11.0 0.53
11.0 7.5 7.4 7.0 6.6 6.1 11.0 11.7 0.89
14.0 10.1 9.9 9.6 8.8 8.1 14.0 12.3 1.29
048
6.0 2.7 2.6 2.4 2.2 2.0
3/4”
6.0
10.6 0.32
9.0 6.0 5.9 5.4 5.2 5.1 9.0 11.2 0.64
12.0 9.5 9.3 8.5 8.3 8.1 12.0 11.9 1.02
16.0 14.2 13.9 12.7 12.3 12.1 16.0 12.8 1.57
060
9.0 4.5 4.4 4.2 4.0 3.8
1”
9.0
16.8 0.29
12.0 6.5 6.3 6.1 5.9 5.7 12.0 17.4 0.47
15.0 8.6 8.1 7.9 7.7 7.5 15.0 18.1 0.69
20.0 12.1 11.2 10.8 10.6 10.4 20.0 19.2 1.09
070
12.0 5.7 5.6 5.4 5.2 5.0
1”
12.0
17.4 0.47
15.0 8.9 8.6 8.2 7.7 6.7 15.0 18.1 0.69
18.0 12.0 11.5 11.0 10.1 8.4 18.0 18.7 0.92
24.0 17.4 16.9 16.5 15.1 11.8 24.0 20.1 1.43
10/15/15 10/15/15
