RB SERIES ENGINEERING GUIDE
RBS041 - Performance Data
Single Speed - PSC (1100 CFM)
EWT
°F
Flow
GPM
WPD HEATING - EAT 70°F COOLING - EAT 80/67°F
psi ft
HC
MBtu/h
Power
kW
HE
MBtu/h
LAT
°F
COP
TC
MBtu/h
SC
MBtu/h
S/T
Ratio
Power
kW
HR
MBtu/h
EER
5.0 1.6 3.8
Operation not recommended
Operation not recommended
20 8.0 3.6 8.2
11.0 8.0 18.5 25.2 2.42 16.9 89.2 3.05
5.0 1.5 3.4 Operation not recommended Operation not recommended
30 8.0 3.4 7.8 30.9 2.96 20.8 94.0 3.06 45.1 31.7 0.70 1.83 51.3 24.6
11.0 7.9 18.1 29.7 2.92 19.7 93.0 2.98 45.7 32.3 0.71 1.72 51.6 26.6
5.0 1.3 3.0 Operation not recommended Operation not recommended
40 8.0 3.2 7.5 34.8 3.03 24.4 97.3 3.36 47.2 32.9 0.70 2.01 54.0 23.5
11.0 7.7 17.8 35.3 3.02 24.9 97.7 3.42 47.8 33.3 0.70 1.89 54.2 25.4
5.0 1.2 2.7 37.5 3.10 26.9 99.6 3.55 48.7 33.8 0.69 2.32 56.6 21.0
50 8.0 3.1 7.1 39.2 3.11 28.5 101.0 3.69 49.3 34.1 0.69 2.19 56.8 22.6
11.0 7.5 17.4 40.8 3.12 30.2 102.3 3.83 49.9 34.3 0.69 2.05 56.9 24.3
5.0 1.0 2.3 42.7 3.16 31.9 103.9 3.96 46.1 32.8 0.71 2.53 54.7 18.2
60 8.0 2.9 6.7 44.5 3.19 33.6 105.4 4.09 46.8 33.1 0.71 2.41 55.0 19.5
11.0 7.4 17.0 46.3 3.22 35.3 106.9 4.21 47.6 33.4 0.70 2.29 55.4 20.8
5.0 0.9 2.0 47.9 3.22 36.9 108.3 4.36 43.4 31.7 0.73 2.73 52.7 15.9
70 8.0 2.8 6.4 49.8 3.27 38.6 109.9 4.46 44.4 32.1 0.72 2.63 53.3 16.9
11.0 7.2 16.7 51.7 3.32 40.4 111.5 4.56 45.3 32.4 0.72 2.52 53.9 18.0
5.0 0.7 1.6 53.5 3.33 42.1 113.0 4.71 40.9 30.8 0.75 2.99 51.1 13.7
80 8.0 2.6 6.0 54.9 3.37 43.4 114.2 4.77 41.7 31.0 0.74 2.85 51.4 14.6
11.0 7.1 16.3 56.3 3.42 44.6 115.4 4.82 42.6 31.3 0.74 2.76 52.0 15.4
5.0 0.5 1.2 59.1 3.43 47.4 117.7 5.04 38.4 29.8 0.78 3.25 49.5 11.8
90 8.0 2.5 5.7 60.0 3.48 48.1 118.5 5.06 39.0 29.9 0.77 3.10 49.6 12.6
11.0 6.9 16.0 60.9 3.52 48.9 119.3 5.07 39.8 30.2 0.76 3.00 50.0 13.3
5.0 0.4 0.9
Operation not recommended
Operation not recommended
100 8.0 2.3 5.3 36.2 28.7 0.79 3.46 48.0 10.5
11.0 6.8 15.6 36.8 29.0 0.79 3.35 48.2 11.0
5.0 0.4 0.9 Operation not recommended
110 8.0 2.1 4.9 33.0 27.3 0.83 3.80 46.0 8.7
11.0 6.6 15.2 33.7 27.7 0.82 3.70 46.3 9.1
5.0 0.4 0.9 Operation not recommended
120 8.0 2.0 4.6 29.8 26.2 0.88 4.22 44.2 7.0
11.0 6.5 14.9 30.4 26.6 0.88 4.10 44.4 7.4
