RB SERIES ENGINEERING GUIDE
RBS018 - Performance Data
Single Speed with Variable Speed ECM or 5-Speed ECM (600 cfm)
EWT
°F
Flow
GPM
WPD HEATING - EAT 70°F COOLING - EAT 80/67°F
psi ft
HC
MBtu/h
Power
kW
HE
MBtu/h
LAT
°F
COP
TC
MBtu/h
SC
MBtu/h
S/T
Ratio
Power
kW
HR
MBtu/h
EER
20
3.0 3.4 7.9
Operation not recommended
Operation not recommended4.0 4.9 11.3
5.0 6.5 15.0 11.7 1.24 7.5 86.1 2.78
30
3.0 3.3 7.6 Operation not recommended Operation not recommended
4.0 4.7 10.9 13.8 1.31 9.4 89.3 3.10 22.1 14.5 0.66 0.71 24.5 31.4
5.0 6.2 14.2 13.5 1.28 9.1 88.8 3.08 22.4 14.8 0.66 0.66 24.7 33.9
40
3.0 3.3 7.6 Operation not recommended Operation not recommended
4.0 4.7 10.9 15.1 1.33 10.6 91.3 3.33 21.9 14.4 0.66 0.84 24.7 26.2
5.0 6.2 14.3 15.1 1.31 10.6 91.3 3.37 21.9 14.5 0.66 0.80 24.7 27.3
50
3.0 3.2 7.4 16.2 1.36 11.6 93.0 3.49 21.8 14.4 0.66 0.99 25.2 22.0
4.0 4.2 9.7 16.5 1.35 11.8 93.4 3.57 21.6 14.3 0.66 0.97 24.9 22.4
5.0 5.2 11.9 16.7 1.34 12.1 93.8 3.65 21.4 14.3 0.67 0.94 24.6 22.7
60
3.0 3.1 7.2 17.9 1.38 13.2 95.5 3.80 20.7 13.9 0.67 1.11 24.5 18.6
4.0 4.1 9.4 18.0 1.38 13.4 95.9 3.85 20.5 13.9 0.68 1.08 24.2 18.9
5.0 5.0 11.6 18.2 1.38 13.6 96.2 3.89 20.2 13.8 0.68 1.06 23.9 19.1
70
3.0 3.0 6.9 19.5 1.39 14.8 98.1 4.11 19.6 13.5 0.69 1.23 23.8 15.9
4.0 3.9 8.9 19.6 1.40 14.9 98.3 4.11 19.3 13.4 0.69 1.20 23.4 16.1
5.0 4.7 10.9 19.8 1.41 15.0 98.5 4.12 19.1 13.3 0.70 1.18 23.1 16.2
80
3.0 2.9 6.7 20.3 1.39 15.6 99.4 4.28 18.4 12.8 0.70 1.42 23.2 13.0
4.0 3.7 8.4 20.6 1.41 15.8 99.8 4.29 18.4 12.9 0.70 1.35 23.0 13.6
5.0 4.4 10.2 20.8 1.42 16.0 100.1 4.30 18.4 12.9 0.70 1.31 22.9 14.1
90
3.0 2.8 6.5 21.2 1.39 16.4 100.7 4.46 17.1 12.2 0.71 1.56 22.5 11.0
4.0 3.6 8.3 21.5 1.41 16.7 101.2 4.47 17.4 12.4 0.71 1.49 22.5 11.7
5.0 4.1 9.5 21.9 1.43 17.0 101.7 4.48 17.8 12.6 0.71 1.44 22.7 12.3
100
3.0 2.7 6.2
Operation not recommended
Operation not recommended
4.0 3.5 8.1 16.6 12.0 0.72 1.62 22.1 10.2
5.0 3.9 9.0 16.8 12.1 0.72 1.57 22.2 10.7
110
3.0 2.6 6.0 Operation not recommended
4.0 3.1 7.0 15.5 11.4 0.73 1.74 21.5 8.9
5.0 3.5 8.1 15.8 11.5 0.73 1.70 21.6 9.3
120
3.0 2.5 5.8 Operation not recommended
4.0 3.0 6.9 13.1 9.8 0.74 1.91 19.6 6.9
5.0 3.4 7.9 13.4 9.9 0.74 1.85 19.7 7.2
