Johnson Controls RBS009 User Manual

67
RB SERIES ENGINEERING GUIDE
RBS070 - Performance Data
Single Speed with Variable Speed ECM or 5-Speed ECM (2200 cfm)
EWT
°F
Flow
GPM
WPD HEATING - EAT 70°F COOLING - EAT 80/67°F
psi ft
HC
MBtu/h
Power
kW
HE
MBtu/h
LAT
°F
COP
TC
MBtu/h
SC
MBtu/h
S/T
Ratio
Power
kW
HR
MBtu/h
EER
20
12.0 5.8 13.4
Operation not recommended
Operation not recommended15.0 9.1 20.9
18.0 12.3 28.4 42.5 3.77 29.6 86.7 3.30
30
12.0 5.7 13.2 Operation not recommended Operation not recommended
15.0 8.9 20.4 50.2 4.36 35.3 90.1 3.37 66.2 41.5 0.63 2.79 75.8 23.7
18.0 12.0 27.7 48.6 3.99 35.0 89.4 3.57 67.1 42.4 0.63 2.62 76.1 25.6
40
12.0 5.7 13.2 Operation not recommended Operation not recommended
15.0 8.9 20.4 56.9 4.40 41.9 93.1 3.79 71.3 46.6 0.65 3.05 81.7 23.4
18.0 12.0 27.7 57.0 4.24 42.6 93.1 3.95 71.4 46.5 0.65 2.92 81.4 24.5
50
12.0 5.6 13.0 63.3 4.42 48.2 95.9 4.20 76.8 52.6 0.68 3.40 88.4 22.6
15.0 8.6 19.8 64.3 4.45 49.2 96.4 4.24 76.3 51.6 0.68 3.31 87.6 23.0
18.0 11.5 26.6 65.4 4.48 50.1 96.8 4.28 75.7 50.6 0.67 3.22 86.7 23.5
60
12.0 5.5 12.7 72.1 4.26 57.6 99.8 4.96 74.2 52.2 0.70 3.78 87.1 19.6
15.0 8.4 19.3 73.6 4.50 58.2 100.4 4.79 74.2 51.7 0.70 3.69 86.7 20.1
18.0 11.2 25.9 75.0 4.74 58.8 101.1 4.64 74.2 51.3 0.69 3.60 86.4 20.6
70
12.0 5.4 12.5 80.9 4.10 66.9 103.7 5.79 71.5 51.8 0.72 4.15 85.7 17.2
15.0 8.2 18.9 82.8 4.55 67.3 104.5 5.34 72.1 51.9 0.72 4.06 85.9 17.7
18.0 11.0 25.5 84.6 4.99 67.6 105.3 4.97 72.6 51.9 0.72 3.97 86.1 18.3
80
12.0 5.3 12.2 88.9 4.69 72.9 107.2 5.56 66.5 50.3 0.76 4.74 82.6 14.0
15.0 7.9 18.2 90.6 4.94 73.7 107.9 5.37 67.2 50.4 0.75 4.52 82.6 14.9
18.0 10.5 24.3 92.2 5.20 74.5 108.7 5.20 68.1 50.5 0.74 4.38 83.0 15.6
90
12.0 5.2 12.0 96.9 5.27 78.9 110.7 5.38 61.4 48.7 0.79 5.18 79.1 11.9
15.0 7.7 17.7 98.4 5.34 80.1 111.4 5.39 62.3 48.9 0.78 4.94 79.2 12.6
18.0 10.1 23.4 99.9 5.41 81.4 112.0 5.41 63.6 49.1 0.77 4.78 79.9 13.3
100
12.0 5.1 11.8
Operation not recommended
Operation not recommended
15.0 7.3 16.7 57.6 46.3 0.80 5.33 75.8 10.8
18.0 9.4 21.7 58.5 46.7 0.80 5.16 76.1 11.3
110
12.0 5.0 11.6 Operation not recommended
15.0 6.7 15.5 52.3 43.7 0.84 5.70 71.7 9.2
18.0 8.4 19.5 53.3 44.4 0.83 5.54 72.2 9.6
120
12.0 4.9 11.3 Operation not recommended
15.0 6.6 15.2 47.5 41.8 0.88 6.10 68.3 7.8
18.0 8.3 19.1 48.5 42.4 0.87 5.92 68.7 8.2
5/1/11
