Table 14: Blower performance CFM - any position (without filter)
Airflow data (SCFM) external static pressure (in. W.C.)Model Speed
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8
High 1375 1350 1325 1300 1275 1225 1200 1175
Medium High 1225 1200 1150 1125 1100 1075 1025 1000
Medium 1150 1100 1075 1050 1000 975 925 900
Medium Low 1050 1025 1000 950 900 875 825 775
040A12
Low 925 900 850 825 775 725 675 625
High 1375 1325 1300 1275 1225 1200 1175 1125
Medium High 1125 1075 1050 1025 975 950 900 850
Medium 1025 975 950 900 850 825 775 725
Medium Low 925 875 850 800 750 725 675 625
060A12
Low 850 825 775 725 675 625 575 525
High 1425 1400 1375 1325 1300 1275 1225 1200
Medium High 1325 1275 1250 1225 1175 1150 1100 1075
Medium 1175 1125 1075 1050 1000 975 925 900
Medium Low 1050 1000 975 925 900 850 800 775
080B12
Low 925 875 825 800 750 700 650 600
High 1750 1700 1675 1625 1575 1550 1500 1475
Medium High 1625 1600 1550 1500 1475 1425 1375 1325
Medium 1400 1375 1325 1275 1225 1200 1125 1100
Medium Low 1275 1225 1175 1125 1100 1050 1000 950
080C16
Low 1150 1100 1050 1000 950 900 850 775
High 2025 1950 1900 1850 1800 1750 1700 1650
Medium High 1825 1750 1700 1625 1600 1525 1475 1425
Medium 1675 1625 1550 1500 1450 1400 1325 1275
Medium Low 1475 1400 1325 1275 1225 1150 1075 1025
080C20
Low 1200 1100 1025 950 875 800 725 650
High 1550 1500 1475 1425 1400 1375 1325 1300
Medium High 1400 1350 1300 1275 1250 1200 1175 1125
Medium 1225 1175 1150 1100 1075 1025 1000 950
Medium Low 1025 975 950 900 850 825 775 750
100B12
Low 900 850 800 775 725 675 650 600
High 1900 1850 1825 1800 1750 1725 1675 1625
Medium High 1700 1675 1625 1600 1550 1525 1475 1425
Medium 1500 1450 1400 1375 1325 1300 1250 1225
Medium Low 1250 1200 1175 1125 1075 1050 1000 950
100C16
Low 1125 1050 1025 975 925 875 850 800
High 1975 1950 1900 1850 1825 1775 1725 1700
Medium High 1825 1775 1725 1675 1650 1600 1550 1500
Medium 1675 1600 1575 1500 1475 1425 1375 1325
Medium Low 1475 1425 1375 1325 1275 1225 1150 1075
100C20
Low 1275 1225 1150 1100 1025 950 825 750
Installation Manual: RL18 Single-Stage Standard ECM Residential Gas Furnaces (Non-condensing Multi-position Standard
Low NOx)
33
