Johnson Controls RW Series User Manual

8
RW SERIES REVERSIBLE CHILLER INSTALLATION MANUAL
K
L
N
M
P
R
A
DETAIL A
S
25.00
24.00
52.00
24.00
SHADED AREAS REPRESENT REQUIRED CLEARANCE
FOR SERVICE & MAINTENANCE OF EQUIPMENT.
T
T
Physical Dimensions, cont.
Model K L M N P R S T*
120-180
57.0
[1448]
42.0
[1067]
63.1
[1603]
15.9
[404]
19.5
[495]
9.7
[246]
1.3
[33]
2.0
[50.8]
240-360
65.0
[1651]
42.0
[1067]
69.9
[1775]
19.9
[505]
19.5
[495]
9.7
[246]
1.8
[46]
2.0
[50.8]
600
70.0
[1778]
42.0
[1067]
76.8
[1951]
22.0
[559]
19.5
[495]
12.7
[323]
1.8
[46]
2.5
[63.5]
All dimensions in inches, [mm]
*T - Units shipped with groove pipe connection
5/12/14
