RW SERIES REVERSIBLE CHILLER INSTALLATION MANUAL
Physical Data
Model Compressor
Refrigerant
Charge*
Total Weight
Shipping Installed
120 Scroll (2)
5.3 720 710
[2.4] [327] [323]
180 Scroll (2)
7.8 838 844
[3.5] [381] [384]
240 Scroll (2)
10.5 1130 1152
[4.8] [514] [524]
360 Scroll (2)
17.9 1320 1388
[8.1] [600] [631]
600 Scroll (2)
27.3 1748 1850
[12.4] [795] [841]
Weights shown in Pounds, [kg] 1/30/2014
* Refrigerant per circuit in Pounds, [kg]
Add 32 lbs [15 kg] for fluid weight when full. (120)
Add 48 lbs [22 kg] for fluid weight when full. (180)
Add 64 lbs [29 kg] for fluid weight when full. (240)
Add 110 lbs [50 kg] for fluid weight when full. (360)
Add 144 lbs [65 kg] for fluid weight when full. (600)
NOTE: See page 12 for minimum fluid volume guidelines.
