MOUNTING THE TOUCH SCREEN COMMUNICATING CONTROL
For most installations, mounting Touch Screen Communicating Control can be done following some
very basic installation steps outlined below. However, there may be some cases where the installer
is not able to penetrate the wall where mounting the Touch Screen Communicating Control, or there
may be an application where the thermostat/control being replaced has left a larger hole than
needed for installation of this control. For these and other applications, (including installation with a
vertical j-box) an installer can obtain a Decorative/Mounting Kit (S1-02815909000).
1. If an existing thermostat or control is being replaced:
a. Remove existing control from wall.
b. Disconnect wires from existing control.
c. Properly discard or recycle old control.
2. Mark on the wall where the Touch Screen Communicating Control will be mounted (standard
height is 5 feet from the floor).
3. Cut a 2” x 2” square hole with the bottom of the square at the mark.
4. Using the mounting back plate as a template, mark the screw holes on the surface where
mounting the Touch Screen Communicating Control. Use a level to insure proper installation.
Voltage Hazard: Live wires can cause electrical shock or equipment damage. Disconnect power
before beginning installation.
Mercury is a hazardous substance, if existing thermostat or control contains any mercury, it
MUST be disposed of properly. The Touch Screen Communicating Control does not contain mer-
cury.
If an existing thermostat was in place, it may be ideal to use the same location for the Touch
Screen Communicating Control.
Make sure that the hole is cut so that the Touch Screen Communicating Control can be leveled
when mounted. See Figure 2 for more detailed mounting information.
To Next Page
