Johnson Controls S300 Series User Manual

S300-DIN-RDR2S Module Hardware Installation
24-10239-413 Rev. A 29
This document contains confidential and proprietary information of Johnson Controls, Inc.
© 2010 Johnson Controls, Inc.
Input and Output Point Signals
The S300-RDR2S module does not turn its output points off when it has not been
polled for more than 5 seconds. (The S300-RDR2S-A module in legacy address
mode, S300-IO8, S300-I16, and S300-SI8 modules turn their output points off if
they have not been polled for more than 5 seconds. The S300-RDR2S-A module in
physical address mode and S300-RDR8S turn their output points off if they have not
been polled for more than 20 seconds.)
Table 3: Input Point Signals (CK721-A/CK72
1/CK720/CK705 Controllers)
Signal
Names
RDR Mode Enabled SIO Mode Enabled
IN11, 
REF
Reader 1
Door Input
Configuration can be 2-state or
4-st
ate.
Input is associated with input point 18
(forced doo
r) and 24 (propped door).
SIO 1
General Purpose Input 1
Input is logically mapped to input
po
int 1.
Configuration can be 2-state or
4-st
ate.
IN12, 
REF
Reader 1
Auxiliary Input
Configuration can be 2-state or
4-st
ate.
2-state auxiliary input is closed for
request to exit state.
4-state auxiliary input must be
calibrated in the quiescent or non
request to exit state.
SIO 1
General Purpose Input 2
Input is logically mapped to input
po
int 2.
Configuration can be 2-state or
4-state.
IN01, 
REF
N/A SIO 1
General Purpose Input 3
Input is logically mapped to input
po
int 3.
Configuration can be 2-state or
4-st
ate.
IN21, 
REF
Reader 2
Door Input
Configuration can be 2-state or
4-st
ate.
Input is associated with input point 18
(forced doo
r) and 24 (propped door).
SIO 2
General Purpose Input 1
Input is logically mapped to input
po
int 1.
Configuration can be 2-state or
4-st
ate.
