Johnson Controls S300 Series User Manual

Hardware Installation S300-DIN-RDR2S Module
30 24-10239-413 Rev. A
This document contains confidential and proprietary information of Johnson Controls, Inc.
© 2010 Johnson Controls, Inc.
IN22, 
REF
Reader 2
Auxiliary Input
Configuration can be 2-state or
4-st
ate.
2-state auxiliary input is closed for
request to exit state.
4-state auxiliary input must be
cal
ibrated in the quiescent or non
request to exit state.
SIO 2
General Purpose Input 2.
Input is logically mapped to input
po
int 2.
Configuration can be 2-state or
4-state.
IN02, 
REF
N/A SIO 2
General Purpose Input 3
Input is logically mapped to input
po
int 3.
Configuration can be 2-state or
4-state.
Table 4: Input Point Signals (CK722 Controllers)
Signal
Names
Reader Terminal Object
Defined
Reader Terminal Object NOT
Defined
IN11, 
REF
Reader (Top)
Door Input
Input is logically mapped to connector
IN1
1.
Configuration can be 2-state or
4-state.
General Purpose Input IN11
Input is logically mapped to connector
IN1
1.
Configuration can be 2-state or
4-st
ate.
IN12, 
REF
Reader (Top)
Auxiliary Input
Input is logically mapped to connector
IN12.
Configuration can be 2-state or
4-st
ate.
2-state auxiliary input is closed for
req
uest to exit state.
4-state auxiliary input must be
calibrated in the quiescent or non
request to exit state.
General Purpose Input IN12
Input is logically mapped to connector
IN12.
Configuration can be 2-state or
4-st
ate.
IN01, 
REF
General Purpose Input IN01
Input is logically mapped to
connector IN01.
Configuration can be 2-state or
4-st
ate.
General Purpose Input IN01
Input is logically mapped to
conn
ector IN01.
Configuration can be 2-state or
4-st
ate.
Table 3: Input Point Signals (CK721-A/CK721/CK720/CK705 Controllers)
Signal
Names
RDR Mode Enabled SIO Mode Enabled
