6. Operating instructions
Read chapter 4. Safety precautions carefully before operating the unit.
6.1 Description of unit
Control system
The compressor unit is controlled by an electronic control system (EC) see Fig. 9. The control sys-
tem is described in a separate manual, delivered with the unit.
Principle drawing
Fig. 9: Positions of valves and components shown on a SAB 151 unit.
EC
151 158 101
192
107
102
Not shown
126
108 163 116
154
106
161
117
103
104
105
159
160
Behind 126
114
