The SNC25152-0x and SNC16122-0x models are both available with integral displays. To order an SNC with an integral
display, add H after the product code number.
Table 15: SNC base features
Product code number Description
F4-SNCxxxx-0x/x Supervisory Network Control Series
Every SNC model includes the following functionality:
• Pluggable terminal blocks
• Site Management Portal (SMP) UI
• Wind River
®
Linux Operating System
• Three mounting clips for direct screw-mounting, or for DIN Rail mounting
Table 16: SNC model features
F4-SNC2515x-0
F4-SNC2515x-0H
F4-SNC2515x-04
F4-SNC2515x-04H
F4-SNC1612x-0
F4-SNC1612x-0H
F4-SNC1612x-04
F4-SNC1612x-04H
Integral
Equipment
Controller
40 Integral I/O points - 25
inputs, 15 outputs
• 14 UI
• 11 BI
• 4 AO
• 7 BO
• 4 CO
40 Integral I/O points -
25 inputs, 15 outputs
• 14 UI
• 11 BI
• 4 AO
• 7 BO
• 4 CO
28 Integral I/O points -
16 inputs, 12 outputs
• 10 UI
• 6 BI
• 4 AO
• 4 BO
• 4 CO
28 Integral I/O points -
16 inputs, 12 outputs
• 10 UI
• 6 BI
• 4 AO
• 4 BO
• 4 CO
F4-SNC25152-0x 1 F4-SNC25152-04x 1 F4-SNC16122-0x 1 F4-SNC16122-04x 1Ethernet
Port
F4-SNC25151-0x 2 F4-SNC25151-04x 2 F4-SNC16121-0x 2 F4-SNC16121-04x 2
Field
Controller
(FC) Bus
1 1 1 1
Devices per
FC Bus/
Trunk
50 4 50 4
SA Bus 1 1 1 1
USB Ports 2 2 2 2
Supported
type of
parent
server
• FX Server software
• FX80 Supervisory Controller
Accessories ordering information
Table 17: SNC accessories ordering information
Product Code Number Description
TL-MAP1810-xx Pocket-sized web server that provides a wireless mobile user interface to Facility Explorer field
controllers, thermostats, and smart rooftop units. Refer to the Mobile Access Portal Gateway Catalog
Page (LIT-1900869) to identify the appropriate product for your region.
Note: The initial release only supports MAP communication with equipment controllers
connected to the FC Bus and not with the application within the SNC (which comes at a later
release).
AS-XFR010-1 Power transformer, no enclosure, class 2, 24 VAC, 92 VA maximum output.
AS-XFR100-1 Power transformer with enclosure, class 2, 24 VAC, 92 VA maximum output.
ACC-TBKINOUT-0 Replacement terminal block kit for input and output terminal blocks. All blocks are removable and
labeled. Kit includes 5 of each 2, 3, and 4-pin terminal blocks
ACC-TBKPWFCSA-0 Replacement terminal block kit for power, FC Bus, SA Bus terminal blocks. All blocks are removable
and labeled. Kit includes 5 of each terminal block type.
F4-SNC Installation Guide 23
