Table 17: SNC accessories ordering information
Product Code Number Description
ACC-USBRS232-0 USB to RS232 adapter. Tested and qualified for use with the SNC.
TL-CCT-0 License enabling CCT software for one user.
TL-SCT-6 System Configuration Tool software for local installations. Upgrade software for previous SCT
versions being upgraded to the latest release.
TL-SCT-0 System Configuration Tool software for local installations. New project software for sites that do
not have a previous version of SCT installed.
FX-FCP-0 License enabling FX Equipment Controller Firmware Package Files required for the Controller
Configuration Tool (CCT).
F4-DLK0350-0 Local Controller Display, 3.5 in. (89 mm) color display with navigation keypad
TL-BUNDLEFX-0 Tool Bundle Facility Explorer, New
F4-MULTENGSW-6 Supervisory controller images for all F4-SNCs on a site
SNC technical specifications
Table 18: SNC2515x-0xx and SNC1612x-0xx
Specification Description
Power requirement Dedicated nominal 24 VAC, Class 2 power supply (North America), SELV power supply (Europe),
at 50/60 Hz (20 VAC minimum to 30 VAC maximum)
Power consumption 33 VA maximum from main power supply
Note: The VA rating does not include any power supplied to the peripheral devices con-
nected to Binary Outputs (BOs) or Configurable Outputs (COs), which can consume up to
12 VA for each BO or CO, for a possible total consumption of an additional 132 VA (maxi-
mum).
Power source +15 VDC power source terminals provide 100 mA total current; quantity of inputs: five, located
in Universal Input terminals; for active (3-wire) input devices
Display Screen 2.4 in (61 mm), 320 x 240 resolution display (-0H and -04H models only)
SA Bus power 15 V at 240 mA maximum
Operating System Wind River
®
Linux LTS 17 (LTS=long-term support)
Processor NXP i.MX6DualLite Processor, 1GHz 32-bit dual core Cortex A9 processor
Memory 16 GB flash nonvolatile memory for operating system, configuration data, and operations data
storage and backup
2 GB SDRAM for operations data dynamic memory
Universal Input (UI)
resolution
Input: 24-bit Analog to Digital converter
Analog Output (AO)
accuracy
Output: +/- 200 mV accuracy in 0–10 VDC applications
Supported
integrations
BACnet/IP, BACnet/SC, BACnet MS/TP
Network and serial
interfaces
1 Ethernet port: SNC25150-0, SNC25150-04, SNC16120-0, SNC16120-04, SNC25152-0,
SNC25152-0H, SNC25152-04, SNC25152-04H, SNC16122-0, SNC16122-0H, SNC16122-04, and
SNC16122-04H
2 Ethernet ports: SNC25151-0, SNC25151-0H, SNC25151-04, SNC25151-04H, SNC16121-0, and
SNC16121-04
Ethernet port(s): 1000/100/10 Mbps; 8-pin RJ45 connector
One FC port (RJ12 6-pin port; connects with 1.5 m [4.9 ft] RJ12 field bus cable)
One SA port (RJ12 6-pin port; connects with 1.5 m [4.9 ft] RJ12 field bus cable)
One optically isolated RS-485 port; with a removable 4-pin terminal block
One optically isolated SA Bus port; with a removable 4-pin terminal block
Two USB A ports. All support USB 2.0 and Open Host Controller Interface [Open HCI]
specification.
F4-SNC Installation Guide24
