Table 18: SNC2515x-0xx and SNC1612x-0xx
Specification Description
Transmission speeds Ethernet communication: 100 or 10 Mbps
The supervisory controller can reside and interoperate on a 1 Gbps network, but does not itself
transmit at 1 Gbps.
Optically isolated, serial communication (FC Bus): 76,800, 38,400, 19,200, 9600, or 1200 bps
(selectable)
Sensor/actuator communication (SA Bus): 38,400 bps
Ambient temperature
conditions
Operating: 0°C to 50°C (32°F to 122°F)
Non-operating: -40°C to 70°C (-40°F to 158°F)
Ambient humidity
conditions
Storage: 5% to 95% RH, 30°C (86°F) maximum dew point conditions
Operating: 0% to 90% RH, 30°C (86°F) maximum dew point conditions
Housing White Polycarbonate and Acrylonitrile butadiene styrene (ABS) blend
IP protection class: IP20
UL flammability rating: UL94-5VB
Mounting On flat surface with screws on three mounting clips or a single 35 mm DIN rail
Dimensions (width x
height x depth)
250 mm x 145 mm x 45.5 mm (9.84 in. x 5.71 in. x 1.79 in.)
Weight 0.65 kg (1.433 lbs)
Compliance United States: UL Listed, File E107041, CCN PAZX, UL 916, Energy Management Equipment;
FCC Compliant to CFR47, Part 15, Subpart B, Class A, Conformance to FIPS 140-2 Level 1 and
validated under NIST Certificate #3389
Canada: UL Listed, File E107041, CCN PAZX7, CAN/CSA C22.2 No. 205, Signal Equipment;
Industry Canada Compliant, ICES-003
Europe: Johnson Controls declares that this product is in compliance with the essential
requirements and other relevant provisions of the EMC Directive.
Australia and New Zealand: RCM Mark, Australia/NZ Emissions Compliant
BACnet International: BTL 135-2020 Listed B-BC/B-RTR/B-BBMD, Protocol Revision 18
United Kingdom: Johnson Controls declares that this product is in compliance with
Electromagnetic Compatibility Regulations, The Electrical Equipment (Safety) Regulations, and
Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment
Regulations.
Table 19: SNC25151-0x and SNC16121-0x (without display)
Specification Description
Power requirement Dedicated nominal 24 VAC, Class 2 power supply (North America), SELV power supply (Europe),
at 50/60 Hz (20 VAC minimum to 30 VAC maximum)
Power consumption 32 VA maximum from main power supply
Note: The VA rating does not include any power supplied to the peripheral devices con-
nected to Binary Outputs (BOs) or Configurable Outputs (COs), which can consume up to
12 VA for each BO or CO, for a possible total consumption of an additional 132 VA (maxi-
mum).
Power source +15 VDC power source terminals provide 100 mA total current; quantity of inputs: five, located
in Universal Input terminals; for active (3-wire) input devices
SA Bus power 15 V at 240 mA maximum
Operating System Wind River
®
Linux LTS 17 (LTS=long-term support)
Processor NXP i.MX6DualLite Processor, 1GHz 32-bit dual core Cortex A9 processor
F4-SNC Installation Guide 25
