TEC Series BACnet® MS/TP Network Temperature and Humidity Controllers Technical Bulletin 21
TEC2645-aaa
8, 9
Device 73aaa N/A
Digital Outputs BV 70 to BV 77 N/A (Future Use)
1. This MS/TP Bus object is readable and only writable if the corresponding override object is set. (For
example, Room Temp has a corresponding override object of Room Temp Override. This
corresponding override object needs to be set to 1 = Override to be able to write Room Temp to a
different value.)
2. This MS/TP Bus object may automatically release after 10 minutes with no BACnet traffic.
3. This MS/TP Bus object is readable and writable.
4. This MS/TP Bus object is valid only if it is written via the network.
5. This MS/TP Bus object is readable only.
6. The BI object type status is available even if the configuration is set to None.
7. If one setpoint of a pair of heating and cooling setpoints (for example, Occupied Heat Setpoint and
Occupied Cool Setpoint) is overridden, the other setpoint of the pair may be automatically adjusted
by the thermostat controller to maintain the minimum deadband between the two setpoints.
8. The designation aaa is the address of the device (from 004 to 127) on the MS/TP network.
9. Max_Master is writable.
Table 4: TEC2645-4 MS/TP Bus Objects (Part 4 of 4)
Point Name Thermostat Point
(Type/Address)
Range
