TEC Series BACnet® MS/TP Network Temperature and Humidity Controllers Technical Bulletin 37
TEC2613-4 and TEC2613-4+PIR Temperature and Humidity
Controllers
Table 9: TEC2613-4 and TEC2613-4+PIR MS/TP Bus Objects (Part 1 of 4)
Point Name Controller Point
(Type/Address)
Range
Room Temp
1
AV 7 -40.0°F/-40.0°C to
122.0°F/50.0°C
Room Temp Override
2, 3
BV 8 0 = Normal
1 = Override
Outdoor Temperature
1
AV 9 -40.0°F/-40.0°C to
122.0°F/50.0°C
Outdoor Temp Override
2, 3
BV 10 0 = Normal
1 = Override
Room Humidity AV 11 0 to 100%
Occupancy
2
MV 12 1 = Local Occupancy
2 = Occupied
3 = Unoccupied
System Mode RTU
2
MV 14 1 = Off
2 = Auto
3 = Cool
4 = Heat
Fan Mode
2
MV 15 1 = On
2 = Auto
3 = Smart
Supply RH AI 17 0 to 100%
Keypad Lockout
2
MV 18 1 = Level 0
2 = Level 1
3 = Level 2
PI Heating Demand AV 20 0 to 100%
PI Cooling Demand AV 21 0 to 100%
Aux BI 24 0 = Off
1 = On
G Fan
4
BI 25 0 = Off
1 = On
Y1 Cool
4
BI 26 0 = Off
1 = On
Y2 Cool
4
BI 27 0 = Off
1 = On
W1 Heat
4
BI 28 0 = Off
1 = On
W2 Heat
4
BI 29 0 = Off
1 = On
DI Status
4, 5
BI 31 0 = Not Activated
1 = Activated
Local Motion
4
BI 33 0 = No Motion
1 = Motion
Effective Occupancy
4
MV 34 1 = Occupied
2 = Unoccupied
3 = Temporary Occupied
Frost Alarm
3, 4, 6
BI 36 0 = Off
1 = On
