Johnson Controls TEC2645-4 - TEC2603-4 and TEC2603-4+PIR MS;TP Bus Objects

TEC Series BACnet® MS/TP Network Temperature and Humidity Controllers Technical Bulletin 33
TEC2603-4 and TEC2603-4+PIR Thermostat Controllers
Table 8: TEC2603-4 and TEC2603-4+PIR MS/TP Bus Objects (Part 1 of 4)
Point Name Thermostat Point
(Type/Address)
Range
Room Temp
1
AV 7 -40.0°F/-40.0°C to
122.0°F/50.0°C
Room Temp Override
2, 3
BV 8 0 = Normal
1 = Override
Outdoor Temperature
1
AV 9 -40.0°F/-40.0°C to
122.0°F/50.0°C
Outdoor Temp Override
2, 3
BV 10 0 = Normal
1 = Override
Occupancy
2
MV 12 1 = Local Occupancy
2 = Occupied
3 = Unoccupied
System Mode RTU
2
MV 14 1 = Off
2 = Auto
3 = Cool
4 = Heat
Fan Mode
2
MV 15 1 = On
2 = Auto
3 = Smart
Supply Temperature
4
AI 16 -40.0°F/-40.0°C to
122.0°F/50.0°C
Keypad Lockout
2
MV 18 1 = Level 0
2 = Level 1
3 = Level 2
PI Heating Demand AV 20 0 to 100%
PI Cooling Demand AV 21 0 to 100%
Aux BI 24 0 = Off
1 = On
G Fan
4
BI 25 0 = Off
1 = On
Y1 Cool
4
BI 26 0 = Off
1 = On
Y2 Cool
4
BI 27 0 = Off
1 = On
W1 Heat
4
BI 28 0 = Off
1 = On
W2 Heat
4
BI 29 0 = Off
1 = On
DI1 Status
4, 5
BI 31 0 = Not Activated
1 = Activated
DI2 Status
4, 5
BI 32 0 = Not Activated
1 = Activated
Local Motion
4
BI 33 0 = No Motion
1 = Motion
Effective Occupancy
4
MV 34 1 = Occupied
2 = Unoccupied
3 = Temporary Occupied
Frost Alarm
3, 4, 6
BI 36 0 = Off
1 = On
