Johnson Controls TEC3630 Series User Manual

TEC3000 Series Single- or Two-Stage Economizer Thermostat Controllers Installation Instructions
30
Control Setup
(Cont)
Frost Protection Yes Yes or No
Aux Mode Not Used Not Used, Occupied NO, Occupied NC,
Occupied Fan NO, Occupied Fan NC, On,
Off
Load Shed Rate Limit 0.066°F 0 to 1°F (0 to 0.5°C)
Load Shed Adjust 4°F 0 to 8°F (0 to 4°C)
Fan Alarm Delay 0 seconds 0 to 300 seconds
Fan Alarm Action (when Fan Alarm
Delay is greater than 0)
Enable Enable or Shutdown
Fan Alarm Reset (when Fan Alarm
Delay is greater than 0)
No Yes or No
Fan Runtime Limit 0 hours 0 to 9,000 hours
Fan Runtime Reset (when Fan
Runtime Limit is greater than 0)
No Yes or No
Supply Air Temperature Alarm Offset 0°F 0 to 10°F (0 to 5.5°C)
Supply Air Temperature Alarm Delay
(when Supply Air Temp Alarm Offset
is greater than 0)
300 seconds 300 to 3,600 seconds
Inputs
BI1 Config Disabled Disabled, Open Window, Open Door, Fan
Lock, Service, Dirty Filter, Motion NC,
Motion NO, Temp Occ, Occupancy
BI2 Config Disabled Disabled, Open Window, Open Door, Fan
Lock, Service, Dirty Filter, Motion NC,
Motion NO, Temp Occ, Occupancy
Supply Temp Sensor Nickel Nickel, Platinum, A99B, 2.25k ohm
negative temperature coefficient (NTC),
10k ohm NTC, 10k ohm NTC Type 3
Supply Temp Offset* 0 -5 to 5 (°F or °C based on Units setting
under Display Settings menu)
* Analog Sensor
Zone Temp Sensor Nickel Nickel, Platinum, A99B, 2.25k ohm NTC,
10k ohm NTC, 10k ohm NTC Type 3
Zone Temp Offset 0 -5 to 5 (°F or °C based on Units setting
under Display Settings menu)
OA Temp Offset 0 -5 to 5 (°F or °C based on Units setting
under Display Settings menu)
OA Temp Sensor Nickel Nickel, Platinum, A99B, 2.25k ohm NTC,
10k ohm NTC, 10k ohm NTC Type 3
Reset Sensors False True or False
Zone Temp Alarm Enabled No Yes or No
Zone Temp Low Limit 55°F 32 to 150°F (0 to 65.56°C)
Zone Temp High Limit 90°F 32 to 150°F (0 to 65.56°C)
Tuning
Table 10: Menus and Submenus (Part 3 of 9)
Level 1 Level 2
(LCD Screen Name)
Level 3
(Default Values)
Available Values
